Engineered for precise speed and torque regulation of three-phase asynchronous motors, the Lenze EVF8244-E frequency inverter provides robust control within the 8200-series architecture. This high-performance AC drive is designed to optimize energy consumption and maintain process stability in demanding industrial automation environments, supporting motors rated up to 4 HP (3.0 kW) at 460V.
| Manufacturer | Lenze |
| Model / SKU | EVF8244-E |
| Alternative Item Code | 33.8244_E |
| Series | 8200-series |
| Product Type | AC Drive / Frequency Inverter |
| Power Rating | 3.0 kW / 4.0 HP |
| Rated Input Voltage | 3-phase 400 V AC to 460 V AC |
| Product Lifecycle Phase | Phase-Out (Legacy Support Available) |
| Dimensions (W x H x D) | 10.20 cm x 40.60 cm x 25.40 cm |
| Shipping Weight | 5.10 kg |
| Commodity Code | 85044095 |
The EVF8244-E belongs to the legacy 8200 Vector family. When replacing this unit in existing panels, note that modern alternatives like the Lenze i550 series do not share the same physical footprint or terminal configurations. Retaining exact spares like the EVF8244-E avoids costly mechanical panel modifications and PLC program rewrites.
This drive relies heavily on vertical convection cooling. In enclosed control panels, ensure a minimum clearance of 100 mm above and below the unit. If ambient temperatures inside the enclosure exceed 40 degC, the continuous output current must be derated to prevent thermal overload faults.
Parameterization can be performed using the EMZ8201BB keypad module or via the LECOM interface using Global Drive Control (GDC) software. Always ensure that the motor cable is shielded and that the shield is grounded with a low-impedance connection directly at the drive's mounting plate to mitigate electromagnetic interference (EMI).
Mount the drive vertically on a flat, vibration-free mounting plate inside a suitable industrial enclosure.
Connect the protective earth (PE) conductor to the designated grounding terminal prior to making any other electrical connections.
Wire the 3-phase AC mains input to terminals L1, L2, and L3 using appropriately sized branch circuit protection.
Connect the shielded motor cable to output terminals U, V, and W, ensuring the shield clamp is securely fastened to the ground plane.
