GT1575-VTBA

Mitsubishi Electric

Mitsubishi Electric GT1575-VTBA GOT1000 Graphic Operator Terminal

SKU GT1575-VTBA

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: GT1575-VTBA
  • Origin United States
  • Product Type: Graphic Operator Terminals
  • Payment: T/T, Western Union
  • Weight: 8.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

GOT1000 Series Graphic Operator Terminals
Quantità
Call sales Contact

Product Description

Description

Designed to provide high-performance human-machine interface (HMI) capabilities, the GT1575-VTBA functions as a robust visualization and control hub within the Mitsubishi Electric GOT1000 platform. This graphic operator terminal features a high-resolution 10.4-inch VGA TFT display, supporting detailed graphical representation of industrial processes and intuitive touch-screen operation.

The unit incorporates 9 MB of internal flash memory for project screen data and operating system storage. Standard built-in communication interfaces include RS-232C and USB ports, facilitating straightforward PLC connection, peripheral interfacing, and project uploads or downloads. Engineered to withstand demanding factory environments, the front panel features an IP67F oil-tight/waterproof rating when properly panel-mounted, while operating on a flexible universal 100-240V AC power supply.

Features

  • 10.4-inch TFT color LCD display with a resolution of 640 x 480 pixels (VGA).
  • Analog resistive touch panel allowing flexible key layouts and precise touch response.
  • 9 MB internal flash memory for efficient project screen management and system files.
  • Integrated RS-232C and USB (Type Mini-B) interfaces for direct controller connection and PC configuration.
  • Universal AC power input compatibility (100 to 240 V AC) for worldwide application.
  • Robust IP67F front panel rating providing advanced dust and oil resistance.

Applications

  • Automotive assembly lines and conveyor control panels.
  • Packaging, labeling, and food processing machinery.
  • Water and wastewater treatment station monitoring.
  • General factory automation and multi-axis motion control visualization.

Technical Specifications

ManufacturerPart Number / ModelSeriesDisplay TypeScreen SizeResolutionPower Supply VoltagePower FrequencyInternal MemoryInterfacesIngress Protection (Front)Ingress Protection (Rear)Operating TemperatureStorage TemperatureShipping Weight
Mitsubishi Electric
GT1575-VTBA
GOT1000
TFT Color LCD
10.4 inches
640 x 480 pixels (VGA)
100 to 240 V AC (+10%, -15%)
50 / 60 Hz
9 MB (Flash Memory)
RS-232, USB (Mini-B)
IP67F (when panel-mounted)
IP20
0 to 50 degC
-20 to 60 degC
8.0 kg

Connections and Interfaces

Interface / Terminal Function / Connection Target
RS-232 Connection 9-pin D-sub (male) for PLC connection, barcode readers, or temperature controllers.
USB Utility Port USB Mini-B interface for direct PC connection, screen data transfer, and OS updates.
Power Terminals Screw terminal blocks for 100-240V AC line, neutral, and protective earth (ground).

Installation Guidelines

  • Panel Mounting: Install the terminal into a clean panel cutout. Tighten the mounting brackets to the specified torque to maintain the IP67F front seal integrity.
  • Clearance: Maintain at least 100 mm of clearance at the top and bottom of the unit, and 50 mm on the sides for natural convection cooling.
  • Grounding: Connect the ground terminal directly to a dedicated protective earth ground (Class D grounding, 100 ohms or less) using a minimum 2 mm² wire.
  • Wiring: Route high-voltage power supply cables separately from low-voltage signal and communication lines to minimize electromagnetic interference.

Compliance and Certifications

  • CE Directive Compliant
  • UL / cUL Listed
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary input voltage range for the GT1575-VTBA?
The GT1575-VTBA operates on a universal input voltage range of 100 to 240 V AC at 50/60 Hz.
What communication interfaces are built directly into this HMI terminal?
The terminal features integrated RS-232C and USB (Mini-B) communication ports for direct PLC interfacing and PC programming.
What protection ratings does the GT1575-VTBA possess?
When properly installed in a control panel, the front section features an IP67F rating for protection against water and oil, while the rear section has an IP20 rating.
How much internal memory is available for screen projects on the GT1575-VTBA?
The terminal is equipped with 9 MB of internal flash memory dedicated to storing user project screens and the terminal operating system.
