Incorporate robust visualization into your control architectures with the GT1675M-VTBA, a premium 10.4-inch touch panel operator terminal from the GOT1000 HMI series. Engineered to deliver exceptional clarity and flexible operator control, this terminal features a high-brightness TFT color LCD panel capable of displaying 65,536 colors with wide viewing angles up to 88 degrees in all directions. Designed for seamless system integration, it coordinates control logic and visualization data to improve on-site operational efficiency.
The unit features an analog resistive touch screen that supports arbitrary key layouts down to a minimum of 2 x 2 dots per key, offering far greater interface design flexibility than traditional matrix panels. With a built-in flash memory capacity of 15 megabytes, industrial operators can store detailed graphical representations, multi-language projects, and comprehensive system log files. Backup capabilities for critical clock and maintenance data are sustained reliably over time via a dedicated GT15-BAT lithium battery module.
| Manufacturer | Mitsubishi Electric |
| Model / Part Number | GT1675M-VTBA |
| Series | GOT1000 |
| Display Type | TFT color LCD (high brightness, wide viewing angle) |
| Screen Size | 10.4-inch |
| Resolution | VGA (640 x 480 dots) |
| Active Display Area | 211 mm (W) x 158 mm (H) |
| Display Colors | 65,536 colors |
| Viewing Angle | 88 degrees (Up, Down, Left, Right) |
| Luminance | 450 cd/m² |
| Backlight Lifespan | Approx. 50,000 hours (ambient temperature 25 degC) |
| Touch Panel Type | Analog resistive film |
| Flash Memory | 15 MB built-in |
| Backup Battery | GT15-BAT lithium battery |
| Storage Temperature | -20 degC to 60 degC |
| Storage Humidity | 10 to 90% RH (non-condensing) |
| External Dimensions | 303 mm (W) x 214 mm (H) x 49 mm (D) |
| Panel Cut-out Dimensions | 289 mm (W) x 200 mm (H) |
| Weight | 2.1 kg (excluding mounting bracket) |
