GT2104-RTBD

Mitsubishi Electric

Mitsubishi Electric GT2104-RTBD GOT2000 HMI

SKU GT2104-RTBD

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: GT2104-RTBD
  • Origin United States
  • Product Type: HMI Touch Panels
  • Payment: T/T, Western Union
  • Weight: 0.4 kg
  • Dimensions: 128 mm x 102 mm x 40 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

GOT2000 Series HMI HMI Touch Panels
Quantità
Call sales Contact

Product Description

Description

Engineers requiring a compact, high-resolution visualization interface for industrial machinery utilize the **GT2104-RTBD** graphic operation terminal. This **HMI touch panel** belongs to the Mitsubishi Electric GOT2000 series, offering a 4.3-inch widescreen display with 65,536 colors for clear graphical representation of machine states and control parameters. Designed for seamless integration with MELSEC PLCs and third-party controllers, it features built-in Ethernet, RS-232, and RS-422/485 communication interfaces to facilitate efficient data exchange on the factory floor.

Features

  • 4.3-inch TFT color widescreen display with 480 x 272 dot resolution.
  • 65,536 display colors for high-fidelity graphic rendering and clear operator alerts.
  • 9 MB user flash memory capacity for project storage, screen data, and logging.
  • Analog resistive touch panel supporting single-point touch operation.
  • Multiple communication interfaces: Ethernet, RS-232, and RS-422/485.
  • SD memory card slot for data logging, backup, and restore operations.
  • IP67F front panel protection rating against dust and water ingress when panel-mounted.

Applications

  • Packaging machinery control and monitoring.
  • Small-scale water treatment automation.
  • HVAC and environmental control systems.
  • Conveyor and material handling systems.
  • Assembly line monitoring and operator interface.

Technical Specifications

Manufacturer Mitsubishi Electric
Part Number/Model GT2104-RTBD
Series GOT2000
Screen Size 4.3 inches
Display Type TFT color LCD
Resolution 480 x 272 dots
Display Color 65,536 colors
Backlight LED (non-replaceable)
Touch Panel Type Analog resistive
Simultaneous Press Single-point touch (simultaneous press prohibited)
User Memory 9 MB (ROM)
Power Supply Voltage 24 V DC
Dimensions (W x H x D) 128 mm x 102 mm x 40 mm
Weight 0.4 kg

Connections and Interfaces

Interface Port Function / Description
Ethernet 1 channel (RJ45) for host PLC communication and network connection
RS-232 1 channel for serial communication with controllers or peripherals
RS-422/485 1 channel for multi-drop serial connection to PLCs and drives
USB Mini-B 1 channel for PC connection (screen design software transfer)
SD Card Slot 1 slot for SD/SDHC memory cards (data logging and OS updates)

Installation Guidelines

  • Panel Mounting: Insert the unit into the panel cutout and secure it using the provided mounting brackets. Tighten the screws to the specified torque to maintain the IP67F protection rating.
  • Clearance: Maintain a minimum clearance of 100 mm from other devices or enclosure walls to ensure adequate ventilation and prevent overheating.
  • Grounding: Connect the functional ground terminal to a dedicated ground point with a ground resistance of 100 ohms or less using a minimum 2 mm square wire.
  • Wiring: Route communication and power cables separately from high-voltage AC lines to minimize electromagnetic interference.

Compliance and Certifications

  • CE Directive Compliant
  • UL / cUL Listed
  • KC (Korean Certification)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the screen size and resolution of the GT2104-RTBD?
The GT2104-RTBD features a 4.3-inch TFT color widescreen display with a resolution of 480 x 272 dots.
Does the GT2104-RTBD support multi-touch operations?
No, the analog resistive touch panel on the GT2104-RTBD supports single-point touch only; simultaneous pressing of multiple points is prohibited.
What communication interfaces are built into this HMI?
It includes built-in Ethernet (RJ45), RS-232, RS-422/485, and a USB Mini-B port for programming.
What is the user memory capacity of the GT2104-RTBD?
The unit features 9 MB of internal flash memory (ROM) for storing project data, screens, and system configurations.
Reviews

More from this brand

Mitsubishi Electric Q06UDEHCPU MELSEC-Q Series Universal PLC CPU Module
Q06UDHCPUMitsubishi Electric Q06UDEHCPU MELSEC-Q Series Universal PLC CPU Module
Mitsubishi Electric FX3U-128MR/ES-A | FX3U Series Main Unit
FX3U-128MR/ES-AMitsubishi Electric FX3U-128MR/ES-A | FX3U Series Main Unit
Mitsubishi MELSEC MR-J3-40A Servo Amplifier | 400W 3-Phase or 1-Phase 200V
MR-J3-40AMitsubishi MELSEC MR-J3-40A Servo Amplifier | 400W 3-Phase or 1-Phase 200V
Mitsubishi MR-J2S-40A-S004 | 400W AC Servo Amplifier
MR-J2S-40A-S004Mitsubishi MR-J2S-40A-S004 | 400W AC Servo Amplifier

GT2104-RTBD

Stock & lead time on request

Call
  • GT2104-RTBD
1 1

Mitsubishi Electric GT2104-RTBD GOT2000 HMI

Only 10 item(s) left in stock

  • Manufacturer: Mitsubishi Electric

  • Product No.: GT2104-RTBD

  • Country of origin:United States

  • Product Type: HMI Touch Panels

  • Payment: T/T, Western Union

  • Weight: 400g

  • Dimensions: 128 mm x 102 mm x 40 mm

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

Engineers requiring a compact, high-resolution visualization interface for industrial machinery utilize the **GT2104-RTBD** graphic operation terminal. This **HMI touch panel** belongs to the Mitsubishi Electric GOT2000 series, offering a 4.3-inch widescreen display with 65,536 colors for clear graphical representation of machine states and control parameters. Designed for seamless integration with MELSEC PLCs and third-party controllers, it features built-in Ethernet, RS-232, and RS-422/485 communication interfaces to facilitate efficient data exchange on the factory floor.

Features

  • 4.3-inch TFT color widescreen display with 480 x 272 dot resolution.
  • 65,536 display colors for high-fidelity graphic rendering and clear operator alerts.
  • 9 MB user flash memory capacity for project storage, screen data, and logging.
  • Analog resistive touch panel supporting single-point touch operation.
  • Multiple communication interfaces: Ethernet, RS-232, and RS-422/485.
  • SD memory card slot for data logging, backup, and restore operations.
  • IP67F front panel protection rating against dust and water ingress when panel-mounted.

Applications

  • Packaging machinery control and monitoring.
  • Small-scale water treatment automation.
  • HVAC and environmental control systems.
