HG-SR421

Mitsubishi Electric

Mitsubishi Electric HG-SR421 HG-SR Series AC Servo Motor

SKU HG-SR421

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: HG-SR421
  • Origin United States
  • Product Type: AC Servo Motors
  • Payment: T/T, Western Union
  • Weight: 8.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

AC Servo Motors HG-SR Series
Quantità
Call sales Contact

Product Description

Description

Designed to deliver high performance in medium-inertia industrial positioning systems, the HG-SR421 AC servo motor offers stable motion control for heavy-duty automation environments. This rotary servo motor operates within the MELSERVO system architecture, providing exceptional torque density and precise positioning feedback. Engineered with high-resolution encoder technology, it enables smooth operation and accurate speed regulation under varying load conditions.

The robust IP67-rated enclosure ensures protection against dust and moisture ingress, making it suitable for demanding industrial installation sites. Utilizing high-performance permanent magnets, this motor achieves a continuous rated output of 4200 W, balancing thermal efficiency with high dynamic responsiveness.

Features

  • Medium-inertia design optimized for stable load control in heavy mechanical systems.
  • High-resolution absolute encoder integration for precise feedback and positioning.
  • Robust environmental protection rating for reliable deployment in harsh industrial conditions.
  • Low-cogging design for uniform rotation even at low operating speeds.
  • Compatible with MELSERVO-MR-J4 servo amplifiers.

Applications

  • Metalworking and machine tool axes.
  • Heavy material handling and gantry transfer systems.
  • Large-scale packaging and printing machinery.
  • Industrial robot positioners and external axes.

Technical Specifications

Manufacturer Mitsubishi Electric
Model Number HG-SR421
Product Type AC Servo Motor
Rated Output Power 4200 W (4.2 kW)
Rated Speed 1000 rpm
Maximum Speed 1500 rpm
Rated Torque 40.1 Nm
Maximum Torque 120 Nm
Supply Voltage 200 VAC
Rated Current 19 A
Maximum Current 61 A
Degree of Protection IP67 (excluding shaft throughput)
Maximum Radial Load 2058 N
Operating Ambient Temperature 0 to 40 degC
Storage Ambient Temperature -15 to 70 degC
Approximate Weight 8.0 kg

Installation Guidelines

  • Mounting Alignment: Ensure precise alignment between the motor shaft and the driven load. Misalignment exceeding specifications can damage the coupling, motor bearings, or shaft.
  • Environmental Protection: While rated IP67, protect the motor from continuous exposure to liquids and avoid submerging. Ensure the cable connectors are correctly sealed and locked.
  • Thermal Management: Provide adequate ventilation space around the motor frame to facilitate natural convection cooling. Do not block the heat-dissipating surfaces.
  • Wiring: Ground the motor frame to the protective earth terminal of the servo amplifier to suppress electromagnetic interference (EMI) and prevent electrical hazards.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the rated power and speed of the Mitsubishi HG-SR421 AC servo motor?
The HG-SR421 has a rated output power of 4200 W (4.2 kW) and a rated speed of 1000 rpm, with a maximum speed capacity of 1500 rpm.
What is the IP rating for the HG-SR421 motor?
The motor features an IP67 degree of protection (excluding the shaft throughput), making it highly resistant to dust and moisture in industrial settings.
What are the rated and peak torque values of this servo motor?
The HG-SR421 delivers a continuous rated torque of 40.1 Nm and can reach a maximum peak torque of 120 Nm.
What is the operating temperature range for the HG-SR421?
The recommended operating ambient temperature range is 0 to 40 degC, while the storage temperature range is -15 to 70 degC.
