Mitsubishi Electric MR-E-40A-KH003 MR-E Series AC Servo Drive

SKU MR-E-40A-KH003

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Mitsubishi Electric
Product No.: MR-E-40A-KH003
Origin United States
Product Type: Servo Drives
Payment: T/T, Western Union
Weight: 2.1 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Designed for high-precision motion control, the Mitsubishi Electric MR-E-40A-KH003 serves as a high-performance AC servo drive within the popular MR-E Series platform. This drive utilizes a sophisticated sine-wave PWM control and current control system to deliver smooth torque, rapid response times, and exceptional positioning accuracy. Engineered to operate with both single-phase and three-phase AC input configurations, the module provides versatile integration options for various machine layouts. It features an integrated dynamic brake for emergency stopping and rapid deceleration, alongside a comprehensive suite of protective functions that safeguard both the drive and the connected servo motor from electrical and thermal faults.

Features

Advanced Control Architecture: Employs sine-wave PWM control and current control systems for precise motor synchronization and minimized torque ripple.
Flexible Power Input: Supports 3-phase 200 to 230 VAC or 1-phase 230 VAC power supplies, accommodating diverse industrial electrical grids.
Built-In Dynamic Brake: Provides integrated dynamic braking capabilities for rapid, controlled deceleration during emergency stop sequences.
Comprehensive Protection Suite: Features built-in diagnostics for overcurrent, regenerative overvoltage, overload (electronic thermal relay), encoder errors, undervoltage, and overspeed.
Robust Thermal Management: Designed to maintain stable performance under demanding duty cycles in industrial control enclosures.

Applications

Packaging and labeling machinery
Material handling and conveyor positioning axes
Textile manufacturing machinery
Small-scale CNC machine tools and custom actuators
Automated assembly systems

Technical Specifications

Manufacturer	Mitsubishi Electric
Model/Part Number	MR-E-40A-KH003
Series	MR-E Series
Product Type	AC Servo Drive / Amplifier
Control System	Sine-wave PWM control, current control system
Input Power Supply (3-Phase)	3-phase 200 to 230 VAC, 50/60 Hz
Input Power Supply (1-Phase)	1-phase 230 VAC, 50/60 Hz
Permissible Voltage Fluctuation (3-Phase)	170 to 253 VAC
Permissible Voltage Fluctuation (1-Phase)	207 to 253 VAC
Permissible Frequency Fluctuation	Within +/- 5%
Dynamic Brake	Built-in
Protective Functions	Overcurrent shut-off, regenerative overvoltage shut-off, overload shut-off (electronic thermal relay), encoder error protection, regenerative error protection, undervoltage, instantaneous power failure protection, overspeed protection, excessive error protection
Weight	2.1 kg

Installation Guidelines

Mounting Orientation: Install the servo drive vertically on a flat, rigid surface to ensure optimal natural convection or forced-air cooling.
Clearance Requirements: Maintain specified clearance distances above, below, and adjacent to the unit to prevent thermal buildup inside the control panel.
Grounding and Shielding: Ensure the protective earth (PE) terminal is securely grounded. Use shielded cabling for encoder and control signals to minimize electromagnetic interference (EMI).
Input Protection: Install recommended molded-case circuit breakers (MCCB) or fuses on the AC input power lines to protect the drive circuitry from upstream electrical faults.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the input voltage requirement for the MR-E-40A-KH003?

The MR-E-40A-KH003 supports either 3-phase 200 to 230 VAC (50/60 Hz) or 1-phase 230 VAC (50/60 Hz) power supplies.

Does this servo drive feature an integrated dynamic brake?

Yes, the MR-E-40A-KH003 comes equipped with a built-in dynamic brake for rapid motor deceleration and emergency stops.

What control system does the MR-E-40A-KH003 utilize?

It utilizes a sine-wave PWM control and current control system to ensure smooth torque delivery and high-precision positioning.

What is the weight of the MR-E-40A-KH003 servo drive?

The drive has a net weight of approximately 2.1 kg.
