Heavy-duty industrial motor control operations require reliable switching components, and the Mitsubishi Electric SD-N300 DC24V delivers high-performance circuit control in demanding B2B environments. This DC-operated magnetic contactor is engineered for non-reversing, Direct On Line (DOL) motor starting and electrical load switching applications. Equipped with a low-consumption 24 VDC control coil, this contactor integrates cleanly into automated control loops, interfacing directly with PLC and DCS systems without the need for interposing high-power relays.
| Manufacturer | Mitsubishi Electric |
|---|---|
| Model Number | SD-N300 DC24V |
| Product Type | Magnetic Contactor |
| Control Voltage | 24 VDC |
| Operation Type | DC Operated |
| Contactor Configuration | Non-reversing |
| Mounting Type | Surface Mounting |
| Terminal Name | Function |
|---|---|
| A1 / A2 | Coil Control Power Supply (24 VDC) |
| 1/L1, 3/L2, 5/L3 | Main Power Source Inputs |
| 2/T1, 4/T2, 6/T3 | Load / Motor Power Outputs |
Ensure that all upstream power is locked out and tagged out prior to installation. This contactor is designed for surface mounting inside a sealed, dust-free industrial enclosure. Maintain standard electrical clearances around the arc chute and ventilation pathways to ensure proper heat dissipation. Connect control and main power cables using correctly sized ring terminals or wire lugs, adhering strictly to the torque requirements specified for the terminal fasteners.
Global Express Shipping
Returns & Warranty
Manufacturer: Mitsubishi Electric
Product No.: SD-N300
Country of origin:United States
Product Type: Magnetic Contactors
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
