Description

Designed for high-speed, large-scale industrial automation applications, the Omron CJ1H-CPU65H serves as a high-performance central processing unit within the highly modular CJ1 PLC series. This CPU module is optimized for complex processing tasks that demand rapid execution times, extensive memory allocation, and seamless synchronization across multiple system components. By providing substantial program capacity and expansive I/O handling, it functions as the core controller in demanding system architectures without requiring a traditional backplane, saving critical control cabinet space.

The CJ1H-CPU65H programmable controller supports advanced instruction execution speeds, ensuring minimal cycle times for precision positioning and sequence control. With its high-capacity memory banks and flexible rack expansion options, industrial operators can scale their automation architecture to manage hundreds of field devices and extensive data logging tasks.

Features

• High-speed processing capability with an LD instruction execution speed of 0.02 microseconds.
• Spacious user program area supporting up to 60 Ksteps to accommodate complex sequence algorithms.
• Extended data memory capacity of 128K words, divided into dedicated DM and multiple EM banks.
• Backplaneless design allows direct module-to-module connection, minimizing space requirements.
• Supports up to 40 expansion units across a maximum of 3 expansion racks.
• Built-in peripheral and RS-232C communication ports for configuration and HMI integration.

Applications

• High-speed packaging and sorting systems
• Semiconductor manufacturing equipment
• Automotive assembly and parts-handling lines
• Multi-axis motion control synchronization
• Water and wastewater treatment processing plant control

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Ensure the system power supply is completely disconnected before mounting or removing the CPU unit.
• Mount the CPU unit securely onto a standard 35mm DIN rail, ensuring the yellow DIN rail mounting hooks are fully locked into place.
• Provide a minimum clearance of 20mm above and below the unit to allow natural convective airflow and prevent heat buildup.
• Ground the PLC system using a dedicated ground wire of 2 square millimeters or thicker, maintaining a ground resistance of less than 100 ohms.
• Verify that the total current consumption of all connected modules does not exceed the maximum output capacity of the system power supply module.

Compliance and Certifications

• CE Directive Compliance
• UL Listed (cULus Industrial Control Equipment)
• NK / Lloyd's Register marine standards (where applicable)
