High-speed, high-accuracy analog control is delivered by the Omron CJ1W-DA042V, a specialized 4-channel analog output module engineered for the Omron CJ-Series PLC platform. This module converts digital values inside the PLC into analog voltage signals, providing high-speed direct conversion capabilities to interface with variable speed drives, actuators, control valves, and other analog field instruments.
Featuring individual channel configuration, the CJ1W-DA042V supports independent signal range selection for each of its four outputs. The system's ultra-fast conversion cycle, scaling down to 20 microseconds for a single point, makes it exceptionally suited for dynamic motion control and high-speed process modulation where real-time accuracy is critical.
| Manufacturer | Omron |
| Model/Part Number | CJ1W-DA042V |
| Series | CJ-Series / CJ1 |
| Module Type | Analog Output Unit (High-speed type) |
| Number of Outputs | 4 points |
| Signal Range (Resolution) |
1 to 5 V (1/10,000) 0 to 10 V (1/20,000) -10 to 10 V (1/40,000) |
| Conversion Period |
1 point: 20 us 2 points: 25 us 3 points: 30 us 4 points: 35 us (Direct conversion provided) |
| Accuracy (at 25 degC) | ±0.3% of F.S. |
| External Connection | Removable terminal block |
| Allocated Unit Numbers | 1 |
| Current Consumption | 0.40 A at 5 VDC |
| Shipping Weight | 2.0 kg |
Mounting: Securely mount the module onto the CJ-series CPU rack or expansion rack. Ensure the locking levers at the top and bottom of the unit are fully engaged to guarantee proper connection to the backplane.
Wiring: Use shielded twisted-pair cables for analog output connections to minimize electromagnetic interference. Route signal lines away from high-voltage power cables or motor lines.
Grounding: Connect the shield wire of the output cables to the ground terminal of the PLC system or control panel. Ensure a single-point ground is maintained to avoid ground loop currents.
System Maintenance: Always power down the PLC system before removing or attaching the terminal block or the module itself to protect sensitive internal CMOS components from ESD and voltage surges.
