Designed to interface directly with Omron CP-series PLC systems, the CP1W-TS001 functions as a dedicated temperature sensor expansion unit for precise thermal monitoring. This compact expansion module enables CP1H, CP1L, and CP1E controllers to acquire process temperature data directly from thermocouple sensors without requiring external signal converters.
By integrating thermal monitoring directly into the PLC backplane, the module optimizes panel space and simplifies programming through direct memory mapping. It features two input channels configured specifically for thermocouple connections, supporting direct temperature reading and transmission to the CPU register area.
| Omron |
| CP1W-TS001 |
| CP Series (CP1W) |
| Temperature Sensor Unit / Expansion I/O Unit |
| 2 |
| Thermocouple (Type K, Type J) |
| 0.1 degC or 1 degC (dependent on range configuration) |
| 250 ms for 2 channels |
| Photocoupler isolation between inputs and internal PLC circuitry |
| 50 mm x 90 mm x 86 mm |
| 0.250 kg |
| Terminal Pin | Function |
|---|---|
| A1 | Thermocouple Input 0 (+) |
| A2 | Thermocouple Input 0 (-) |
| A3 | No Connection (NC) |
| B1 | Thermocouple Input 1 (+) |
| B2 | Thermocouple Input 1 (-) |
| B3 | No Connection (NC) |
