CP2E-S40DT-D

Omron

Omron CP2E-S40DT-D CP2E Series Programmable Controller CPU Unit

SKU CP2E-S40DT-D

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: CP2E-S40DT-D
  • Origin Japan
  • Product Type: Programmable Controllers
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

CP2E Series Programmable Controllers
Quantità
Call sales Contact

Product Description

Description

Engineered for compact machine control, the CP2E-S40DT-D serves as a highly efficient programmable logic controller (PLC) within the Omron CP2E Standard (S-type) family. This controller is designed to handle essential automation tasks with a space-saving footprint, offering an ideal balance of integrated input/output points and communication interfaces. Featuring 40 built-in I/O points, the unit provides direct connectivity to sensors, actuators, and human-machine interfaces without the immediate need for expansion modules.

The system operates on a standard 24 VDC power supply, making it compatible with typical industrial control panels. It utilizes high-speed processing to manage digital inputs and sinking transistor outputs, facilitating rapid response times in basic positioning and sequence control applications. Built-in micro-USB functionality ensures simple programming and diagnostics using standard engineering software environments.

Features

  • Integrated 40-point digital I/O configuration (24 inputs and 16 outputs).
  • Transistor outputs with sinking (NPN) configuration for reliable solid-state switching.
  • Standard 24 VDC power requirement for industrial control environments.
  • Built-in micro-USB port for programming, configuration, and monitoring.
  • Compact housing designed for standard 35 mm DIN rail mounting or direct panel installation.
  • Low current consumption to minimize load on panel power supplies.

Applications

  • Packaging and labeling machinery
  • Conveyor and material handling systems
  • Small-scale pumping and fluid control systems
  • HVAC and environmental control automation
  • Automated assembly and sorting equipment

Technical Specifications

Manufacturer Omron
Model / Part Number CP2E-S40DT-D
Product Series CP2E Series (S-type Standard)
Product Type Programmable Controller CPU Unit
Number of I/O Points 40 points
Number of Inputs 24 points (24 VDC)
Number of Outputs 16 points
Output Type Transistor (Sinking / NPN)
Supply Voltage 24 VDC
Current Consumption 0.34 A at 5 VDC, 0.02 A at 24 VDC
Programming Interface Micro-USB (Type-B)
Mounting Method 35 mm DIN Rail or Panel Mount

Installation Guidelines

  • Provide a minimum clearance of 50 mm above and below the unit to ensure adequate convective air circulation.
  • Always ground the protective earth (PE) terminal to a dedicated ground of 100 ohms or less to prevent electrical noise interference.
  • Verify the polarity of the 24 VDC supply before applying power to prevent damage to the internal circuitry.
  • Keep signal lines and DC communication cables separated from high-voltage AC power lines within the enclosure.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the power supply requirement for the Omron CP2E-S40DT-D?
The CP2E-S40DT-D requires a standard 24 VDC power supply for operation.
What is the output configuration of this CPU unit?
It features 16 sinking (NPN) transistor outputs.
How many total I/O points are built into the CP2E-S40DT-D?
The unit includes 40 built-in I/O points, consisting of 24 digital inputs and 16 digital outputs.
Does this controller support programming via USB?
Yes, it has an integrated micro-USB port designed for system programming, configuration, and monitoring.
