CQM1-PR001-E

Omron

Omron CQM1-PRO01-E Sysmac Handheld Programming Console

SKU CQM1-PR001-E

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Omron
  • Product No.: CQM1-PR001-E
  • Origin Japan
  • Product Type: PLC Programming Consoles
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

PLC Programming Consoles Sysmac CQM1
Quantità
Call sales Contact

Product Description

Description

For direct, hardware-level diagnostic access and local code modifications, the CQM1-PRO01-E handheld programming console provides a reliable interface for Omron Sysmac PLC systems. This programming tool plugs directly into the peripheral port of the host controller, facilitating direct memory addressing, operational monitoring, and instruction modification without the necessity of a dedicated field programming PC.

Engineered for industrial survival, the CQM1-PRO01-E contains a high-contrast liquid crystal display (LCD) and a tactile, sealed membrane keyboard that resists dust, moisture, and common industrial contaminants. It enables maintenance technicians and system engineers to switch PLC operating modes, read or write program instructions, clear error codes, and adjust system parameters directly at the control cabinet panel.

Features

  • Compatible with multiple legacy Omron PLC series, including CQM1, CPM1, CPM1A, CPM2A, SRM1, and C200HX/HG/HE.
  • Tactile membrane keyboard with specialized system and instruction keys for rapid sequence execution.
  • Multi-character LCD panel displays real-time execution states, address registers, and diagnostic codes.
  • Bus-powered design operates directly from the host PLC interface, eliminating the need for batteries or external power packs.
  • Enables secure configuration of basic parameters and absolute system memory manipulation.

Applications

  • On-site machine commissioning and immediate parameter adjustment.
  • Industrial manufacturing line diagnostic monitoring and error isolation.
  • Legacy automated packaging, textile, and metalworking machinery maintenance.

Technical Specifications

ManufacturerPart Number / ModelProduct TypeSupported SystemsDisplay TypeInput InterfaceOperating VoltagePower ConsumptionOperating TemperatureStorage TemperatureOperating HumidityWeight
Omron
CQM1-PRO01-E (also identified as CQM1-PR001-E)
Handheld Programming Console
Sysmac CQM1, CPM1, CPM1A, CPM2A, SRM1, C200HX/HG/HE
Alphanumeric Liquid Crystal Display (LCD)
tactile membrane sheet keys
5 VDC (supplied via host PLC peripheral port)
0.15 A maximum
0 to 55 degC
-20 to 75 degC
35% to 85% RH (non-condensing)
2.0 kg (approximate shipping weight including integrated connection cable)

Connections and Interfaces

Interface Type Function / Connection Method
Integrated Peripheral Cable Connects directly to the PLC CPU peripheral interface port for bus power and serial data transmission.

Installation Guidelines

  • Power down the host PLC CPU before attaching or detaching the programming console cable to avoid communication bus spikes.
  • Ensure the connection cable is completely seated and the retention screws or clips are secured prior to powering up the system.
  • Do not route the programming console cable parallel to high-voltage, high-current, or AC motor supply lines to minimize electromagnetic noise coupling.
  • Store the console in a dry, clean enclosure when not in active engineering use to preserve the membrane keyboard interface.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
Which Omron PLC series are compatible with the CQM1-PRO01-E console?
The CQM1-PRO01-E is natively compatible with Sysmac CQM1, CPM1, CPM1A, CPM2A, SRM1, and C200HX/HG/HE series controllers using the standard peripheral connection.
Does the CQM1-PRO01-E programming console require external batteries?
No, the handheld console does not require external batteries or power supplies. It draws its 5 VDC operating voltage directly from the PLC's peripheral port.
Can I hot-swap the CQM1-PRO01-E while the PLC is powered on?
It is highly recommended to turn off power to the PLC CPU before connecting or disconnecting the console to prevent communications bus lockups or transient electrical issues.
