Omron H7CX-A4-N | Omron | H7CX-A Series Multifunction Counter/Tachometer

SKU H7CX-A4-N

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Omron
Product No.: H7CX-A4-N
Origin Japan
Product Type: Multifunction Counter/Tachometer
Payment: T/T, Western Union
Weight: 2.0 kg
Dimensions: 4.8 cm x 8.4 cm x 4.8 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The H7CX-A4-N is a robust multifunction counter/tachometer from the H7CX-A series, designed for versatile process monitoring in industrial automation. Featuring a 4-digit high-visibility display, this unit is configured for 1-stage setting and provides flexible output capabilities, supporting both contact output and transistor output configurations. This model is engineered to operate on a universal 100 to 240 VAC power supply, making it highly adaptable to various global industrial power standards. Equipped with screw terminals for secure and straightforward wiring, it is an ideal solution for precision counting and speed regulation tasks in factory environments.

Features

Dual Functionality: Easily switchable between counter and tachometer modes
Display: Clear 4-digit digital readout for easy monitoring
Output Flexibility: Supports contact output or contact + transistor output configurations
Power Versatility: Universal input voltage range of 100 to 240 VAC
Connection: Standard screw terminals ensuring reliable long-term electrical contact

Applications

Batch counting and totalization on assembly lines
Rotational speed (RPM) monitoring for conveyor motors
Industrial process timing and sequence control
Flow rate measurement and totalizing

Technical Specifications

Parameter	Specification
Manufacturer	Omron
Model	H7CX-A4-N
Product Type	Multifunction Counter/Tachometer
Digits	4
Setting Type	1-stage
Output Type	Contact / Contact + Transistor
Supply Voltage	100 to 240 VAC (50/60 Hz)
Connection Type	Screw terminals
Dimensions	4.8 cm x 8.4 cm x 4.8 cm
Shipping Weight	2 kg

Installation Guidelines

Panel Preparation: The unit is intended for panel mounting. Ensure the panel cutout meets the manufacturer's specifications to maintain a firm, vibration-resistant mount.
Wiring: Connect the power supply to the designated terminals. Ensure that all input sensors and output loads are correctly wired per the device’s terminal diagram. Always use shielded cabling for signal inputs to minimize interference in industrial environments.
Environment: Avoid mounting in locations subject to direct sunlight, high humidity, or temperatures exceeding the operational limit.
Programming: Use the front-panel keys to configure the operating mode (Counter/Tachometer) and set the desired target values before commissioning the system.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

Does the H7CX-A4-N support AC power supply voltages?

Yes, this model is designed to operate on a universal supply voltage of 100 to 240 VAC at 50/60 Hz.

What kind of output options are available for this specific model?

This unit offers flexible output options, supporting contact output, or a combined contact and transistor output configuration.

Is the H7CX-A4-N a 4-digit or 6-digit device?

The H7CX-A4-N is a 4-digit device, as indicated by the '4' in its model number.
