Omron R7D-AP08H SmartStep Servo Drive

SKU R7D-AP08H

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Omron
Product No.: R7D-AP08H
Origin Japan
Product Type: Servo Drives
Payment: T/T, Western Union
Weight: 1.7 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Engineered for precise speed and torque control in automated systems, the Omron R7D-AP08H is a high-performance AC servo drive operating within the SmartStep series ecosystem. This drive bridges the gap between stepper systems and fully closed-loop AC servo technologies, offering simple configuration alongside high-speed dynamic response. Designed to power AC servo motors up to 750 W, the unit operates on a 200 VAC input class, making it ideal for integration into standard industrial control panels.

The R7D-AP08H utilizes advanced processing algorithms to minimize tracking errors and optimize motor performance under varying load profiles. Its robust power stage accommodates substantial momentary overcurrent requirements, ensuring reliable operation during rapid acceleration and deceleration cycles without sacrificing system longevity.

Features

Closed-loop AC servo performance with the operational simplicity of a stepper system.
Direct integration with 200 VAC power distribution networks.
High peak output current capacity of up to 13.9 A rms to handle sudden torque demands.
Compact footprint designed for space-optimized electrical enclosures.
Built-in protection circuits preventing damage from overvoltage, overcurrent, and thermal overload.

Applications

Packaging and labeling machinery
Pick-and-place material handling gantries
Semiconductor manufacturing tools
Automated assembly and test systems

Technical Specifications

Manufacturer	Omron
Model/Part Number	R7D-AP08H
Series	SmartStep
Product Type	AC Servo Drive
Input Voltage	200 VAC
Rated Power Output	750 W
Continuous Output Current (rms)	4.4 A
Momentary Maximum Output Current (rms)	13.9 A
Ambient Operating Temperature	0 to 55 degC
Ambient Storage Temperature	-20 to 85 degC
Operating/Storage Humidity	90% max. (non-condensing)
Operating Atmosphere	Free of corrosive gases
Weight	1.7 kg

Installation Guidelines

Mounting Orientation: Install the drive vertically on a flat, non-flammable panel surface to maximize convection cooling.
Clearance: Maintain a minimum clearance of 10 mm on either side and 50 mm above and below the drive unit to allow sufficient airflow.
Grounding: Ensure the drive is solidly connected to the central protective earth (PE) ground busbar to minimize electromagnetic interference (EMI).
Atmospheric Protection: Verify that the enclosure provides adequate IP rating to protect the drive from dust, conductive particles, and corrosive gases.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary input voltage rating for the Omron R7D-AP08H?

The Omron R7D-AP08H servo drive is rated for a 200 VAC input.

What motor power rating is compatible with the R7D-AP08H?

This SmartStep servo drive is rated to operate with AC servo motors up to 750 W.

Can the R7D-AP08H handle peak current overloads?

Yes, it supports a momentary maximum output current of up to 13.9 A rms, with a continuous rated output of 4.4 A rms.

What are the ambient temperature limits for safe operation?

The drive is designed to operate within an ambient temperature range of 0 to 55 degC.
