Schneider 140XBP00300 Modicon Quantum Backplane

SKU 140XBP00300

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: 140XBP00300
Origin France
Product Type: Digital Modules
Payment: T/T, Western Union
Weight: 0.86 kg
Dimensions: 24,5cm x 29,5cm x 5cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The 140XBP00300 is a 3-slot backplane (rack) designed for the Modicon Quantum automation platform. This backplane serves as the structural and electrical foundation for the system, facilitating communication and power distribution between the CPU, power supply, and various I/O modules. Designed for high-availability industrial control applications, the 140XBP00300 provides a reliable mounting interface for up to three modules, ensuring robust signal integrity and mechanical stability within the Modicon Quantum architecture.

Features

Compatibility: Modicon Quantum series modules
Slot Capacity: 3 slots
Durable structural design for industrial rack mounting
Facilitates power and bus communication across connected modules

Applications

Distributed control system (DCS) expansions
PLC rack-based industrial automation
Local I/O management in manufacturing processes
Upgrade or replacement projects for existing Modicon Quantum systems

Technical Specifications

Parameter	Specification
Manufacturer	Schneider Electric
Product Range	Modicon Quantum
Model	140XBP00300
Product Type	Backplane (Rack)
Slot Count	3
Dimensions	24.50 cm x 29.50 cm x 5.00 cm
Weight	0.86 kg
Origin	France
Commodity Code	85381000
Product Phase	Phase-Out

Installation Guidelines

Mounting: Secure the backplane to the enclosure mounting plate using the provided hardware to ensure vibration resistance and electrical grounding.
Grounding: Verify that the backplane is properly connected to the common ground of the enclosure to minimize electrical noise and ensure system safety.
Module Insertion: Always power down the system before inserting or removing modules from the backplane to prevent electrical arcing or damage to the module connectors.
Environment: Ensure the installation area allows for adequate airflow around the rack to prevent heat buildup from the mounted modules.
