Description

The ATS01N109FT is a compact Soft Starter from the Altistart 01 range, engineered by Schneider Electric to ensure smooth starting and stopping of three-phase asynchronous motors. Rated for a nominal current of 9 A, this unit is designed to support a wide operational voltage range from 110 V to 480 V, covering motor power requirements from 1.1 kW to 4 kW depending on the application.

By limiting the starting torque and current surges, the ATS01N109FT prevents mechanical shock and voltage drops during motor startup. Its lightweight, low-profile construction makes it an ideal solution for applications where cabinet space is limited, providing a reliable and efficient method to extend the service life of motors and mechanical drive components.

Features

• Smooth motor acceleration to reduce mechanical wear
• Nominal current rating of 9 A
• Supports a wide operational voltage range (110–480 V)
• Compatible with asynchronous motors (1.1 kW to 4 kW)
• Space-saving design for installation in tight enclosures
• High reliability for industrial and commercial motor control

Applications

• Small industrial conveyor systems
• Fans and pumps
• Packaging and bottling machinery
• Automated gate and door control systems
• Small-scale material handling equipment

Technical Specifications

Installation Guidelines

• Mounting: Install the soft starter in a vertical orientation on a non-flammable surface to facilitate effective airflow and heat dissipation.
• Clearance: Maintain the recommended clearance distances around the unit to prevent thermal overload.
• Wiring: Connect the power supply and motor cables securely, ensuring torque settings meet the specifications provided in the manual.
• Control: Use appropriate shielded cabling for control signals to prevent electromagnetic interference from power lines.
• Environment: Ensure the operating environment is free from conductive dust, corrosive chemicals, and excessive moisture.
