Description

The ATS22C41S6 is an Altistart 22 soft starter designed for the controlled starting and stopping of asynchronous motors. Manufactured by Schneider Electric, this device is engineered to provide smooth acceleration, reducing mechanical stress and current surges during motor startup in industrial applications.

This soft starter is rated for a nominal current of 410 A and operates within a supply voltage range of 230 V to 600 V. It supports motor power ratings ranging from 110 kW to 250 kW, making it suitable for a wide array of demanding drive configurations. The ATS22C41S6 is a robust solution for enhancing equipment longevity and optimizing energy performance in heavy-duty industrial environments.

Features

• Soft starting and deceleration control for asynchronous motors
• Rated current capacity of 410 A
• Voltage operational range: 230 V to 600 V
• Power range coverage: 110 kW to 250 kW
• Designed to minimize mechanical and electrical stress on motor drives

Applications

• Pumping systems
• Fan and ventilation units
• Compressor assemblies
• Centrifugal machinery
• Conveyor systems

Technical Specifications

Installation Guidelines

• Mounting: Ensure the unit is mounted in a vertical position within an enclosure to facilitate proper airflow through the cooling fins.
• Clearance: Maintain the minimum recommended clearance distances around the unit to prevent overheating during operation.
• Environment: Protect the device from excessive dust, moisture, and corrosive gases. Ensure the operating ambient temperature does not exceed manufacturer limits.
• Grounding: Verify that the chassis is connected to a common system ground to ensure reliable operation and safety compliance.
• Cable Selection: Use power cables rated for the nominal current of 410 A. Ensure all connections are torqued according to the provided documentation.
