Description

The ATV12HU30M3 is a compact Altivar 12 variable frequency drive designed for simple industrial machines and commercial applications. Rated for 3 kW (4 HP), this drive operates on a 200-240 V three-phase supply. It is engineered for straightforward setup and integration, offering reliable speed control for small asynchronous motors in applications where ease of use and space efficiency are primary requirements.

Features

• Power rating: 3 kW (4 HP)
• Input voltage: 200-240 V (Three-phase)
• Compact, space-saving design
• User-friendly configuration and operation
• Optimized for small-scale industrial and commercial motor control
• Efficient speed regulation for asynchronous motors

Applications

• Small conveyors
• Pumping systems
• Fan and ventilation units
• Packaging machines
• Commercial kitchen appliances (e.g., mixers, slicers)

Technical Specifications

Installation Guidelines

• Mounting: Mount the drive vertically on a flat, non-combustible surface. Maintain adequate clearance above and below the unit for airflow to ensure proper cooling.
• Environmental: Protect the unit from dust, moisture, and corrosive vapors. Operating ambient temperatures must stay within the specified range to prevent thermal derating.
• Wiring: Connect the three-phase power supply to the input terminals and the motor to the output terminals. Keep control signal wiring physically separate from power cabling to minimize electrical noise.
• Grounding: Secure a solid connection to the system protective earth (PE) terminal to ensure operator safety and EMC performance.
• Commissioning: Use the drive's built-in HMI to input motor parameters (such as nominal current and frequency) before initial startup to ensure accurate control.
