Description

The ATV21WD30N4C is an Altivar 21 variable frequency drive designed for robust motor control in industrial and building automation environments. Rated for 30 kW (40 HP) and operating on a 480 V supply, this drive is equipped with an integrated Class B EMC filter to ensure compliance with strict electromagnetic compatibility standards. The unit features an IP54-rated enclosure, providing effective protection against dust and splashing water, making it suitable for demanding installation sites. The ATV21WD30N4C provides efficient speed regulation for asynchronous motors, focusing on energy savings and operational reliability in HVAC and fluid-handling applications.

Features

• Power rating: 30 kW (40 HP)
• Input voltage: 480 V
• Integrated Class B EMC filter for low electromagnetic emission
• IP54 enclosure rating for dust and moisture protection
• Reliable speed and torque control for industrial processes
• Optimized for HVAC and pumping applications

Applications

• Commercial and industrial HVAC systems
• Large-scale water and wastewater pumping
• Cooling tower fan regulation
• Building automation systems
• Industrial ventilation control

Technical Specifications

Installation Guidelines

• Mounting: Due to the weight and IP54 rating, ensure the drive is securely mounted on a structurally sound, vertical wall or panel surface.
• Environmental: The IP54 rating allows for operation in more challenging environments, but the unit should still be protected from direct weather exposure and extreme temperatures.
• Wiring: Utilize shielded motor cables to maintain the integrity of the Class B EMC filtering. Properly route control and power cabling to avoid electromagnetic noise.
• Grounding: Establish a high-integrity connection to the system protective earth to ensure safety and performance compliance.
• Cooling: Ensure the installation area provides sufficient clearance for heat dissipation, as the drive performance can be affected by internal temperature accumulation.
