Schneider Altivar 312 ATV312H018M3 Variable Frequency Drive

SKU ATV312H018M3

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATV312H018M3
Origin France
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 1.3 kg
Dimensions: 7,20cm x 14,50cm x 12,20cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The ATV312H018M3 is an Altivar 312 variable frequency drive built for general-purpose motor control applications. This compact inverter unit is rated for 0.18 kW with an output current of 1.5 A, operating on a 200-240 V three-phase power supply. It provides essential motor speed and torque regulation, helping to maintain operational efficiency in industrial environments where space is limited. The ATV312H018M3 is a reliable solution for basic drive tasks, ensuring steady control performance within its specified electrical parameters.

Features

Three-phase operation (200-240 V)
Compact footprint for space-constrained installations
Designed for general-purpose industrial motor control
1.5 A output current capacity
Integrated control functions for efficient motor management

Applications

Small conveyor systems
Fan and pump speed regulation
Packaging machinery
General machine control
Material handling equipment

Technical Specifications

Specification	Details
Manufacturer	Schneider Electric
Range	Altivar
Subrange	312
Product Type	Variable frequency drives
Power Rating	0.18 kW
Rated Current	1.5 A
Supply Voltage	200-240 V (Three-phase)
Dimensions	7.20 x 14.50 x 12.20 cm
Weight	1.30 kg
Commodity Code	85044095
Product Status	Phase-Out

Installation Guidelines

Mounting: Install the drive in a vertical position on a flat, non-combustible surface. Ensure that the cooling fins are not obstructed to maintain optimal thermal performance.
Environmental: Protect the unit from high humidity, dust, and corrosive vapors. Operating ambient temperature should remain within the manufacturer-recommended range to avoid derating.
Wiring: Maintain clear separation between control signal cables and power cables to reduce the risk of electromagnetic interference. Use shielded motor cables for compliance with EMC standards.
Grounding: Connect the drive chassis to a reliable protective earth (PE) terminal to ensure operator safety and system stability.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary electrical rating for the ATV312H018M3?

This model is rated for 0.18 kW at 200-240 V three-phase, with a maximum current output of 1.5 A.

What is the lifecycle status of the Altivar 312 series?

The Altivar 312 series is currently classified in the Phase-Out product lifecycle stage.

Is this drive suitable for restricted cabinet spaces?

Yes, its compact dimensions of 7.20 x 14.50 x 12.20 cm make it ideal for installations where mounting space is limited.

What are the recommended environmental conditions for this VFD?

The drive should be installed in a dry, clean environment, free from corrosive gases, and mounted vertically with proper ventilation clearance.
