Schneider Altivar 61 ATV61HD15N4Z Variable Frequency Drive

SKU ATV61HD15N4Z

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: ATV61HD15N4Z
  • Origin France
  • Product Type: Variable Frequency Drives
  • Payment: T/T, Western Union
  • Weight: 8.73 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Altivar 61 Variable Frequency Drives
Quantità
Call sales Contact

Product Description

Description

The ATV61HD15N4Z is an Altivar 61 variable frequency drive engineered for high-performance motor control in industrial HVAC and fluid management applications. This drive provides a power output of 15 kW (20 HP) and operates on a three-phase 480 V supply. The unit is housed in an IP20-rated enclosure and includes EMC filtering to mitigate electromagnetic interference. Note that this specific configuration is supplied without a graphic terminal. The ATV61HD15N4Z offers advanced control algorithms to ensure precise speed regulation, energy efficiency, and operational stability for various industrial motor systems.

Features

  • Power rating: 15 kW (20 HP)
  • Input voltage: 480 V (Three-phase)
  • Integrated EMC filtering
  • IP20 protection rating
  • Compact physical design for efficient panel integration
  • Configuration: Supplied without graphic terminal

Applications

  • HVAC systems
  • Fluid management and pump control
  • Fan and ventilation systems
  • Commercial and industrial motor drive applications

Technical Specifications

Specification Details
Manufacturer Schneider Electric
Range Altivar
Subrange 61
Product Type Variable frequency drives
Power Rating 15 kW (20 HP)
Input Voltage 480 V (Three-phase)
Protection Rating IP20
Weight 8.73 kg
Commodity Code 85044095
Product Status Phase-Out

Installation Guidelines

  • Mounting: Install the drive in a vertical position on a stable, non-combustible surface. Ensure that the cooling airflow is not obstructed.
  • Environmental: Protect the unit from excessive dust, moisture, and corrosive vapors. Maintain ambient operating temperatures within the specified limits to prevent thermal derating.
  • Wiring: Maintain clear segregation between control wiring and power conductors to reduce electromagnetic interference. Use shielded motor cables for compliance with EMC requirements.
  • Grounding: Connect the drive chassis to a solid protective earth (PE) terminal to ensure operator safety and reliable system operation.
  • Terminal Note: As this unit is supplied without a graphic terminal, ensure an appropriate interface is available or already installed within the system for configuration and monitoring.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the power rating of the ATV61HD15N4Z drive?
This model is rated for 15 kW (20 HP) at 480 V.
Does this model come with a graphic terminal?
No, the ATV61HD15N4Z configuration is supplied without a graphic terminal.
What is the current lifecycle status of the Altivar 61 series?
The Altivar 61 series is currently classified in the Phase-Out product lifecycle stage.
What is the ingress protection rating for this unit?
The drive features an IP20 protection rating.
