Schneider Altivar VW3A1102 Variable Frequency Drives

SKU VW3A1102

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: VW3A1102
Origin France
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 0.23 kg
Dimensions: 23,00cm x 16,50cm x 7,5cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The VW3A1102 is a remote mounting kit specifically engineered for Altivar series variable speed drive graphic terminals. This door mounting kit enables the operator display to be installed on the front panel of an enclosure, providing an IP54 ingress protection rating that shields the terminal from dust and moisture in challenging industrial environments. The VW3A1102 allows for centralized control and real-time monitoring of drive parameters without requiring direct access to the interior of the cabinet.

Features

Compatible with Altivar variable speed drive graphic terminals
IP54 protection rating for enhanced environmental resistance
Facilitates remote access and monitoring on enclosure doors
Durable construction for industrial use

Applications

Remote operation of variable frequency drives
Cabinet-mounted HMI for motor control systems
Industrial automation enclosures requiring external display access

Technical Specifications

Parameter	Specification
Manufacturer	Schneider Electric
Product Range	Altivar
Model	VW3A1102
Product Type	Door Mounting Kit
Ingress Protection	IP54
Dimensions	23.00 cm x 16.50 cm x 7.50 cm
Weight	0.23 kg
Commodity Code	85371099
Product Phase	Active

Installation Guidelines

Cutout Requirements: Ensure the enclosure door is prepared with the correct cutout dimensions as specified in the official drive manual to maintain the IP54 seal.
Gasket Placement: Verify that the seal/gasket is properly seated between the mounting kit frame and the enclosure door to maintain the environmental rating.
Securing: Tighten all mounting hardware evenly to ensure a secure, vibration-resistant fit against the panel surface.
Cable Routing: Use the recommended remote cable lengths provided by the drive manufacturer to ensure signal integrity between the terminal and the variable speed drive.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary purpose of the VW3A1102 kit?

The VW3A1102 is a door mounting kit that allows a graphic terminal for an Altivar variable speed drive to be mounted externally on an enclosure door.

What level of environmental protection does this kit provide?

This mounting kit provides an IP54 rating, ensuring protection against dust ingress and splashing water.

Is the VW3A1102 compatible with all drives?

The VW3A1102 is specifically designed for use with Altivar series variable speed drive graphic terminals. Please consult your specific drive's technical documentation to confirm compatibility.
