Schneider Altivar 212 ATV212WD45N4C Variable Frequency Drive

SKU ATV212WD45N4C

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATV212WD45N4C
Origin France
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 77.0 kg
Dimensions: 116cm x 44cm x 45cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The ATV212WD45N4C is a high-performance variable frequency drive from the Altivar 212 series, specifically engineered for HVAC (Heating, Ventilation, and Air Conditioning) applications. With a power rating of 45 kW and an input voltage of 480V (3-phase), this frequency controller is optimized for building management systems, pump control, and fan operation. The unit features an IP55 ingress protection rating, providing robust defense against dust and low-pressure water jets, and includes an integrated EMC class C1 filter to ensure electromagnetic compatibility in commercial and industrial environments.

Features

Power Rating: 45 kW
Input Voltage: 480V, 3-Phase
Ingress Protection: IP55 (suitable for wall-mounted or harsh environment installations)
Integrated EMC Filter: Class C1 compliance
Application Focus: HVAC, pumps, and fans
Optimized energy efficiency for motor control

Applications

HVAC system optimization
Commercial building ventilation systems
Water distribution and booster pump stations
Building management system (BMS) integration

Technical Specifications

Parameter	Specification
Manufacturer	Schneider Electric
Range	Altivar
Subrange	212
Model	ATV212WD45N4C
Power Rating	45 kW
Input Voltage	480 V (3-Phase)
IP Rating	IP55
Weight	77.00 kg
Dimensions	116.00 cm x 44.00 cm x 45.00 cm
Commodity Code	85044095
Product Phase	Active

Installation Guidelines

Mounting: Due to the weight of 77 kg, ensure the mounting surface is structurally capable of supporting the drive. Use appropriate lifting equipment.
Ventilation: Maintain specified clearance distances around the unit to ensure adequate heat dissipation and airflow.
Grounding: Solidly ground the drive chassis to the main ground bus to ensure the effectiveness of the EMC filter and personnel safety.
Cable Routing: Segregate power cabling from control and signal wiring to minimize inductive interference and ensure signal integrity.
Environmental: Ensure the operating environment temperature is within the manufacturer's specified limits for IP55-rated enclosures.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary application for the Altivar 212 series?

The Altivar 212 series is specifically designed for HVAC applications, such as controlling fans, pumps, and compressors in building management systems.

What is the IP rating for the ATV212WD45N4C?

This model has an IP55 rating, which provides protection against dust and low-pressure water jets, making it suitable for environments where exposure to moisture or dust is possible.

Does this drive include an EMC filter?

Yes, this model includes an integrated EMC filter compliant with Class C1, which helps minimize electromagnetic interference in commercial and industrial settings.
