LC1D95P7

Schneider Electric

Schneider Electric LC1D95P7 TeSys D Contactor

SKU LC1D95P7

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: LC1D95P7
  • Origin France
  • Product Type: Contactors
  • Payment: T/T, Western Union
  • Weight: 1.57 kg
  • Dimensions: 14cm x 13,5cm x 9,5cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Contactors TeSys D
Quantità
Call sales Contact

Product Description

The LC1D95P7 is a TeSys D series Contactor, designed for high-performance switching in power and motor control applications. Engineered for reliability, this contactor is rated for 95 A (AC-3 duty) at voltages up to 440 V, making it suitable for demanding industrial motor control requirements. It features a control coil voltage of 230 V AC and is built for consistent performance in various operational environments.

Features

  • Range: TeSys D
  • Type: Contactor
  • Rated Operational Current: 95 A (AC-3, up to 440 V)
  • Control Circuit Voltage: 230 V AC
  • Robust design for industrial switching applications
  • Reliable performance for motor control and power distribution

Applications

  • Industrial motor starting and control
  • Heating, ventilation, and air conditioning (HVAC) systems
  • Power distribution and circuit switching
  • Automated production machinery

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Range TeSys D
Product Type Contactors
Rated Current 95 A
Control Voltage 230 V AC
Dimensions 14 x 13.5 x 9.5 cm
Weight 1.57 kg
Commodity Code 85364900
Product Phase Active

Installation Guidelines

  • Mounting: Designed for mounting on a 35 mm DIN rail or panel mounting. Ensure the mounting surface is stable and level.
  • Wiring: Connect line and load conductors to the power terminals. Use correctly sized conductors and tighten terminal screws to the manufacturer’s specified torque to ensure reliable contact.
  • Control Wiring: Connect the 230 V AC control circuit to the coil terminals (A1/A2). Verify the control voltage matches the coil rating before energizing.
  • Environment: Install within an appropriate enclosure to protect the contactor from moisture, conductive dust, and extreme temperatures.
  • Maintenance: Periodically check terminal tightness and inspect for signs of contact erosion or debris accumulation during routine inspections.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the rated operational current of the LC1D95P7?
This contactor has a rated operational current of 95 A (AC-3, up to 440 V).
What is the control voltage for this model?
The control circuit coil voltage is 230 V AC.
What is the current status of the TeSys D product line?
This product is currently in the Active phase of its product lifecycle.
What is the weight of the LC1D95P7 contactor?
The unit weighs 1.57 kg.
