Description

The ATV312HU40M3 is a compact variable frequency drive from the Schneider Electric Altivar 312 series, designed for general-purpose motor control applications. This drive operates within a 200-240V supply voltage range for 3-phase systems and is capable of managing motor power up to 4 kW with a rated output current of 17.5 A. Engineered to improve process efficiency, it provides precise control over motor speed and torque, helping to reduce energy consumption and mechanical strain in industrial environments.

Features

• Compatible with 200-240V 3-phase power systems
• Rated power capacity: 4 kW
• Rated operational current: 17.5 A
• Compact design for optimized cabinet space utilization
• Designed for general-purpose industrial automation

Applications

• Conveyor systems
• HVAC units and ventilation systems
• Manufacturing process machinery
• Industrial pump and fan control
• Material handling equipment

Technical Specifications

Installation Guidelines

• Mounting: Install the drive in a vertical position on a stable, non-flammable surface to facilitate proper airflow through the cooling channels.
• Environment: Ensure the unit is installed in an environment free from conductive dust, corrosive gases, and extreme humidity to prevent component failure.
• Clearance: Maintain the recommended minimum distances around the unit to ensure adequate heat dissipation and prevent thermal overload.
• Wiring: Use appropriately rated cables for input and motor output connections, adhering to local electrical safety standards.
• Grounding: Secure a reliable protective earth connection to the drive chassis to ensure operator safety and EMC performance.
