Schneider Electric 140XTS01206 Modicon Quantum Cable Assembly

SKU 140XTS01206

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: 140XTS01206
Origin France
Product Type: PLC Cable Assemblies
Payment: T/T, Western Union
Weight: 2.32 kg
Dimensions: 30.0 x 32.5 x 5.8 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Engineered to streamline point-to-point wiring in high-density control enclosures, the Schneider Electric 140XTS01206 establishes a secure, low-resistance connection interface for Modicon Quantum digital modules. This heavy-duty cable assembly simplifies the integration of digital I/O modules into legacy and active control architectures, minimizing manual termination errors and accelerating commissioning timelines.

Key Features

Pre-terminated with a robust Modicon Quantum I/O connector to ensure a gas-tight, vibration-resistant interface.
Generous 1.8-meter (6-foot) length accommodates complex routing paths across standard industrial enclosures.
High-power configuration (HP CF ASSY) designed to handle digital signal transitions with minimal voltage drop.
Integrated strain relief mechanism within the connector hood to protect internal conductors from physical stress.

Industrial Applications

Modicon Quantum PLC system expansions and hardware migrations.
Heavy industrial control panels requiring pre-fabricated wiring harnesses to maintain high signal integrity.
Retrofitting legacy automation systems where rapid, plug-and-play I/O deployment is critical to minimizing downtime.

Technical Specifications

Manufacturer	Schneider Electric
Model Number	140XTS01206
Series	Modicon Quantum
Product Type	Digital Module Cable Accessory
Cable Length	1.8 meters (6 feet)
Connector Type	Quantum I/O Connector
Product Lifecycle Phase	Phase-Out (Legacy Support)
Country of Origin	France
Commodity Code	85444290
Shipping Weight (Calculated)	2.32 kg
Package Dimensions (Calculated)	30.0 x 32.5 x 5.8 cm

Empirical Engineering Insights

Alternative Models & Compatibility: The 140XTS01206 is engineered specifically for Modicon Quantum digital I/O modules. When replacing legacy assemblies, verify that the terminal block pin configuration matches your specific module's hardware revision, as some legacy modules require distinct terminal block depths.

Application Pitfalls & Engineering Notes: Avoid routing this cable assembly adjacent to high-voltage motor supply lines or variable frequency drives (VFDs) without adequate metallic shielding separation. Due to its 1.8-meter length, excessive coiling of unused cable can introduce parasitic inductance; route in a sweeping "S" pattern rather than tight loops.

Commissioning & Wiring Tips: During commissioning, ensure the connector's retaining screws are hand-tightened to prevent back-out under low-frequency structural vibration. Always verify continuity from the module terminal to the field termination block before energizing the system.

Installation Guidelines

CRITICAL WARNING: Before installing or removing any cable assembly, ensure all primary and auxiliary power sources to the PLC rack and field devices are completely de-energized. Failure to do so can result in electrical arcing, module damage, or severe personal injury.

Inspect the cable assembly and connector pins for any physical damage, bent pins, or contamination before insertion.

Align the connector with the interface port on the Modicon Quantum digital module and push firmly until fully seated.

Secure the connector locking screws to the specified torque to maintain physical integrity and electrical contact under vibration.

Route the cable through standard wire ducts, ensuring the minimum bend radius is maintained to prevent internal conductor fatigue.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the 140XTS01206 cable assembly?

It provides a pre-fabricated, high-power connection interface between Modicon Quantum digital I/O modules and field termination points, reducing wiring time and errors.

What is the physical length of this cable assembly?

The cable has a length of 1.8 meters, which is equivalent to approximately 6 feet.

Is this cable assembly compatible with all Modicon Quantum modules?

It is designed specifically for Modicon Quantum digital modules requiring the high-power connector interface. Always verify your specific module's hardware manual for compatibility.

What precautions should be taken regarding the bend radius of this cable?

Avoid sharp bends near the connector hood to prevent strain on the internal conductors. Maintain a generous bend radius within the wire ducting.
