A9N15645

Schneider Electric

Schneider Electric A9N15645 Acti9 STI Fuse Disconnector

SKU A9N15645

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: A9N15645
  • Origin France
  • Product Type: Fuse-Disconnectors
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 13cm x 8cm x 2,5cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Fuse-Disconnectors
Quantità
Call sales Contact

Product Description

Description

The A9N15645 is an Acti9 STI fuse-disconnector from Schneider Electric, designed for the reliable protection and isolation of electrical circuits. This unit features a 1-pole + neutral (1P+N) configuration and is rated for a 10 A current. It is specifically engineered to accommodate 8.5 x 31.5 mm cylindrical fuses. As part of the Acti9 system, it provides high levels of safety and modularity for electrical distribution. Currently in the Phase-Out lifecycle stage, this disconnector remains a critical component for maintaining, upgrading, or repairing established electrical installations.

Features

  • Configuration: 1-pole + neutral (1P+N)
  • Rated Current: 10 A
  • Fuse Size: Compatible with 8.5 x 31.5 mm cylindrical fuses
  • Modularity: Compact design for standard DIN rail installation
  • Safety: Designed for reliable circuit isolation and protection
  • Lifecycle Status: Phase-Out (ideal for legacy system support)

Applications

  • Electrical distribution panel protection
  • Control circuit protection in industrial and commercial buildings
  • Maintenance and upgrades for legacy Acti9 installations
  • Circuit isolation in control panels
  • General-purpose protection of auxiliary circuits

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Brand Acti9
Product Type Fuse-disconnector
Poles 1P + N
Rated Current 10 A
Fuse Size 8.5 mm x 31.5 mm
Dimensions 13.00 cm x 8.00 cm x 2.50 cm
Weight 0.14 kg
Commodity Code 85369085
Product Phase Phase-Out

Installation Guidelines

  • Mounting: The device is designed for easy snap-on mounting onto standard DIN rails within electrical distribution boards.
  • Wiring: Ensure all power is disconnected before installing or replacing fuses. Use appropriate terminal torque to ensure secure connections and prevent overheating.
  • Fuse Selection: Always use a fuse with the correct current rating and characteristics (8.5 x 31.5 mm) as specified for the application to ensure effective protection.
  • Maintenance: Since this is a Phase-Out product, ensure that your inventory of compatible fuses is maintained to avoid downtime during future maintenance cycles.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the configuration of this fuse-disconnector?
The A9N15645 features a 1-pole + neutral (1P+N) configuration.
What size fuses are compatible with this device?
It is designed to hold 8.5 x 31.5 mm cylindrical fuses.
What is the current rating of the A9N15645?
The rated current for this device is 10 A.
What does the 'Phase-Out' status mean for this product?
It indicates that the product is reaching the end of its active lifecycle, making it best suited for maintaining or repairing existing installations.
