Schneider Electric Altivar 950 ATV950D18N4 Variable Frequency Drives

SKU ATV950D18N4

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATV950D18N4
Origin France
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 37.5 kg
Dimensions: 80cm x 60cm x 75cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The ATV950D18N4 is an Altivar 950 upright frequency converter engineered by Schneider Electric for demanding industrial motor control and process automation applications. This advanced variable frequency drive delivers a rated power output of 18.5 kW and operates within a supply voltage range of 400 to 480 V. Designed with an integrated brake chopper, it provides superior dynamic braking performance and energy management during rapid deceleration and frequent start-stop cycles. Housed in a robust IP55 rated enclosure, it offers excellent protection against dust and water jets, making it ideal for harsh or washdown plant environments. Typical industrial applications include centrifugal pumps, high-inertia fans, material handling conveyors, extruders, and heavy-duty industrial mixing machinery. It is fully compatible with standard Schneider Electric Altivar automation architectures and digital control networks.

Features

Altivar 950 upright frequency converter designed for high-performance industrial motor control
Rated power output of 18.5 kW for 400 to 480 V three-phase electrical systems
Integrated brake chopper for precise deceleration and dynamic braking capability
Rugged IP55 rated enclosure for reliable operation in dusty and wet environments
Advanced connectivity and process monitoring features for optimal system integration

Applications

Industrial centrifugal pumps and booster stations
Heavy-duty material handling conveyors and transport systems
Extruders, mixers, and processing machinery drives
Industrial ventilation fans and high-inertia air handling units

Technical Specifications

Technical Parameter	Specification
Brand	Schneider Electric
Manufacturer	Schneider Electric
Range	Altivar
Subrange	950
Type of product	Variable frequency drives
Product phase	Active
Power Rating	18.5 kW
Supply Voltage	400 to 480 V
Braking	With brake chopper
Degree of Protection	IP55
Dimensions	80.00 x 60.00 x 75.00 cm
Weight	37.50 kg
Commodity Code	85044095
Export Control Regulations (ECCN)	N

Installation Guidelines

Mount the upright frequency converter securely onto a rigid, vertical wall or support structure capable of supporting the total unit weight of 37.50 kg.
Maintain recommended clearance spaces above and below the drive enclosure to ensure proper thermal dissipation and cooling airflow.
Connect the three-phase power supply lines, motor cables, and dynamic braking resistor wiring using shielded cables in accordance with EMC guidelines.
Verify proper control wiring, safety interlocks, and parameter configurations prior to energizing the drive system.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What power rating and voltage range does the ATV950D18N4 drive support?

The drive delivers a rated power output of 18.5 kW and operates within a voltage range of 400 to 480 V.

Does the frequency converter include built-in dynamic braking capabilities?

Yes, it is equipped with an integrated brake chopper to manage energy during rapid deceleration and frequent start-stop cycles.

What degree of protection and physical dimensions does the unit feature?

It features an IP55 rated enclosure, measures 80.00 cm by 60.00 cm by 75.00 cm, and weighs 37.50 kg.
