Schneider Electric ATS01N206RT Altistart 01 Soft Starter

SKU ATS01N206RT

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATS01N206RT
Origin France
Product Type: Soft starters
Payment: T/T, Western Union
Weight: 0.54 kg
Dimensions: 17,5cm x 15,2cm x 5,5cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The ATS01N206RT is a soft starter from the Altistart 01 series designed for the controlled starting and stopping of three-phase asynchronous motors. By regulating the voltage ramp, this device minimizes mechanical stress and current surges during motor acceleration, facilitating smoother operation in industrial machinery. It is specifically engineered to support motors with a power rating of 2-3 HP and handles a rated operational current of 6 A within a supply voltage range of 440-480V. The unit is optimized for compact control panel installations where space efficiency is required.

Features

Soft start and soft stop control for three-phase asynchronous motors
Integrated bypass contactor for reduced heat dissipation during operation
Compact physical footprint for high-density DIN rail mounting
Simplified adjustment settings for starting time and deceleration
Voltage ramp regulation to limit torque transients

Applications

Conveyor systems and material handling equipment
Small pumps and fan assemblies
Packaging machines
Centrifugal machinery
Light-duty industrial motor applications

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Range	Altistart
Subrange	1
Model	ATS01N206RT
Rated Operational Current	6 A
Supply Voltage	440-480 V
Motor Power Rating	2-3 HP
Commodity Code	84798997
Product Phase	Active
Weight	0.54 kg
Dimensions (H x W x D)	17.5 x 15.2 x 5.5 cm

Installation Guidelines

Mounting: Designed for standard DIN rail installation. Ensure vertical orientation to maintain cooling airflow.
Cooling: Maintain adequate clearance around the unit to prevent thermal buildup; do not obstruct ventilation slots.
Wiring: Use appropriate wire gauges corresponding to the 6 A current rating. Ensure all power terminals are securely tightened to prevent contact resistance.
Environment: Install in a clean, dry location free from excessive dust, moisture, and corrosive atmospheres.
Protection: It is recommended to use appropriate branch circuit protection (fuses or circuit breakers) upstream of the soft starter as per local electrical codes.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the ATS01N206RT?

It is designed to provide smooth starting and stopping for three-phase asynchronous motors by controlling the voltage ramp to reduce mechanical stress.

Does this soft starter require an external bypass contactor?

No, the unit features an integrated bypass contactor to reduce heat generation once the motor reaches nominal speed.

What is the rated motor power capacity for this model?

The device is rated for motors with a power capacity of 2-3 HP.

What is the recommended mounting orientation?

The unit must be mounted vertically to ensure optimal cooling and ventilation through the device housing.
