ATS46C32N

Schneider Electric

Schneider Electric ATS46C32N Altistart 46 Soft Starter

SKU ATS46C32N

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: ATS46C32N
  • Origin France
  • Product Type: Soft starters
  • Payment: T/T, Western Union
  • Weight: 44.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Soft starters
Quantità
Call sales Contact

Product Description

Description

The Schneider Electric ATS46C32N is a soft starter from the Altistart 46 range, designed for controlled starting and stopping of three-phase AC induction motors. This unit is rated for a continuous current of 320 A and supports a maximum operational voltage of 500 V. It is engineered to reduce mechanical stress on drive systems and minimize inrush current during motor startup. The device features compatibility with TeSys D and F-line contactors, providing a flexible solution for high-power motor control applications.

Features

  • Smooth acceleration and deceleration for three-phase motors
  • Rated current: 320 A
  • Maximum voltage: 500 V
  • Power ratings: 100 HP @ 208 V, 125 HP @ 230 V, 250 HP @ 460 V
  • Compatible with TeSys D and F-line contactor series

Applications

  • High-power industrial pump and fan systems
  • Conveyor belt start-up control
  • Compressor motor soft starting
  • Large-scale industrial machinery acceleration

Technical Specifications

Parameter Specification
Manufacturer Schneider Electric
Range Altistart 46
Product Type Soft starters
Current Rating 320 A
Max Voltage 500 V
Product Phase Obsolete
Weight 44.00 kg
Commodity Code 85044095

Installation Guidelines

  • Mounting: Ensure the soft starter is mounted in a vertical position within an adequately ventilated enclosure to dissipate heat generated during operation.
  • Clearance: Follow the manufacturer's specified spacing requirements above and below the unit to prevent thermal faults.
  • Grounding: Connect the soft starter chassis to a common protective earth bus to maintain electromagnetic compatibility and safety.
  • Wiring: Use appropriately sized power cables and ensure all terminal connections are torqued to specifications to prevent overheating.
  • Contactors: When using with TeSys D or F-line contactors, verify the correct wiring configuration for the bypass or isolation setup as required by the application.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the rated current for the ATS46C32N?
The soft starter is rated for 320 A.
What is the maximum operating voltage?
The maximum rated voltage for this unit is 500 V.
Is this soft starter compatible with contactors?
Yes, it is compatible with Schneider Electric TeSys D and F-line contactor series.
What is the current lifecycle status of this product?
The ATS46C32N is classified as an obsolete product.
