Description

The ATS48D17Y is a robust soft starter from the Altistart 48 range, engineered to provide smooth acceleration and deceleration for three-phase asynchronous motors. This unit is designed to mitigate mechanical stress on drive trains and reduce high-current surges during motor startup, thereby protecting the electrical network and extending the lifespan of mechanical components.

With a nominal current rating of 14 A and a wide supply voltage range of 208–690 V AC, this soft starter is suitable for motor power ratings ranging from 4 kW to 15 kW. It incorporates advanced torque control technology, making it ideal for a variety of industrial applications, including pumps, fans, and compressors. Although the Altistart 48 series is now in a Phase-Out lifecycle stage, it remains a highly reliable and widely respected solution for legacy motor control systems.

Features

• Torque Control: Utilizes Schneider Electric's patented Torque Control System (TCS) to ensure smooth, shock-free starting and stopping.
• Versatile Voltage Range: Supports global power grid standards from 208 V to 690 V.
• Compact Integration: Optimized physical design for efficient panel mounting.
• Advanced Protection: Built-in motor and soft starter protection, including thermal monitoring and phase imbalance detection.
• Operational Versatility: Suitable for a broad range of industrial applications, including centrifugal and piston pumps, fans, and conveyors.

Technical Specifications

Installation Guidelines

• Mounting: Install the soft starter vertically in an electrical cabinet to ensure optimal airflow. Leave sufficient clearance (typically 10 cm) above and below the unit to prevent heat buildup.
• Wiring: Connect the line supply to terminals (1/L1, 3/L2, 5/L3) and the motor leads to (2/T1, 4/T2, 6/T3). Use suitably rated cables based on the 14 A nominal current.
• Bypass Contactor: Many installations benefit from an external bypass contactor to remove the soft starter from the circuit after the motor has reached full speed, reducing internal heating.
• Grounding: Securely connect the enclosure to the protective earth (PE) system to ensure EMC compliance and operator safety.
• Commissioning: Use the integrated keypad or commissioning software to configure the starting parameters (acceleration ramp, current limit) specific to the motor load.
