Schneider Electric ATV61HU40N4Z Altivar 61 Variable Frequency Drive

SKU ATV61HU40N4Z

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATV61HU40N4Z
Origin France
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 5.72 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

The ATV61HU40N4Z is a Variable Frequency Drive (VFD) from the Altivar 61 range, engineered to provide precise motor control for industrial and commercial applications. This device operates with a power rating of 4 kW (5 HP) and is designed to handle input voltages ranging from 380V to 480V. It features an IP20-rated enclosure, providing protection against solid objects while maintaining compact installation dimensions. The drive utilizes internal control algorithms to manage speed regulation, supporting efficient motor operation and torque management across various load profiles.

Features

Rated Power: 4 kW (5 HP)
Supply Voltage: 380...480V
Enclosure Rating: IP20
Precision speed regulation for motor control
Designed for reduced mechanical wear on driven equipment

Applications

HVAC systems (fans and pumps)
Constant torque industrial machinery
Material handling systems
Process control equipment

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Range	Altivar 61
Product Type	Variable Frequency Drive
Power Rating	4 kW (5 HP)
Supply Voltage	380...480V
Enclosure	IP20
Weight	5.72 kg
Commodity Code	85044095
Product Phase	Phase-Out

Installation Guidelines

Cooling: Ensure adequate ventilation around the drive to prevent overheating; maintain clearance as specified in the installation manual for heat dissipation.
Mounting: The unit is designed for panel mounting. Ensure the surface is flat and can support the weight of the drive (5.72 kg).
Wiring: Connect the 3-phase power supply to the designated input terminals and the motor leads to the output terminals. Observe proper torque settings for all terminal connections.
Grounding: Maintain a solid protective earth connection to the drive chassis to ensure electromagnetic compatibility and safety.
Environmental: Operate within specified temperature and humidity ranges; avoid environments with excessive dust, moisture, or corrosive gases.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the power rating of the ATV61HU40N4Z?

This drive is rated for 4 kW (5 HP) motor applications.

What is the input voltage range for this drive?

The drive supports an input voltage range of 380V to 480V.

Does this model have an environmental protection rating?

Yes, it is equipped with an IP20 enclosure, which protects against solid objects but does not provide protection against liquids.

Is the Altivar 61 series currently in production?

No, this specific product is currently in the Phase-Out stage of its product lifecycle.
