Schneider Electric ATV71HD37N4S337 Altivar 71 Variable Frequency Drive

SKU ATV71HD37N4S337

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATV71HD37N4S337
Origin France
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 34.0 kg
Dimensions: 63,40cm x 35,00cm x 31,60cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

The ATV71HD37N4S337 is a Variable Frequency Drive (VFD) from the Altivar 71 range, engineered for high-performance motor control in demanding industrial environments. With a power rating of 37 kW (50 HP) and an operating voltage of 480V, this drive is suited for complex automation processes. It features an integrated EMC filter to assist in meeting electromagnetic compatibility requirements and includes a graphic terminal for enhanced parameter monitoring, diagnostics, and local configuration.

Features

Rated Power: 37 kW (50 HP)
Supply Voltage: 480V
Integrated EMC filter for improved electromagnetic compatibility
Graphic display terminal for intuitive operation and diagnostics
Robust design for medium to large-scale industrial applications

Applications

High-performance production lines
Complex motion control systems
Large-scale pumping and ventilation stations
Industrial process automation

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Range	Altivar 71
Product Type	Variable Frequency Drive
Power Rating	37 kW (50 HP)
Supply Voltage	480V
Dimensions	63.40 x 35.00 x 31.60 cm
Weight	34.00 kg
Commodity Code	85044095
Product Phase	Phase-Out

Installation Guidelines

Mounting: Ensure vertical installation on a sturdy surface capable of supporting the 34.00 kg weight. Maintain required clearances above and below the unit for proper cooling airflow.
Cooling: This unit generates heat during operation; ensure the installation area has sufficient ventilation or forced cooling to maintain ambient temperatures within specifications.
Wiring: Use shielded motor cables to take advantage of the integrated EMC filter. Ensure all power connections are tightened to the torque specifications provided in the manual.
Grounding: A high-integrity connection to a common protective earth is critical for VFD reliability and to minimize electromagnetic noise.
Terminal Setup: The graphic terminal should be used for initial setup and calibration of motor parameters before beginning full-scale operations.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary power rating of the ATV71HD37N4S337?

This drive is rated for 37 kW (50 HP) motor applications.

What does the S337 suffix indicate regarding hardware?

This specific configuration includes an integrated EMC filter and a graphic terminal for enhanced user interaction.

What is the physical weight of this drive?

The unit weighs 34.00 kg.

What is the current status of the Altivar 71 series?

The Altivar 71 range, including this model, is currently in the Phase-Out stage of its product lifecycle.
