The LC1D253MD is a TeSys D series Contactor, designed for high-reliability switching in power and control circuit applications. Engineered by Schneider Electric, this device is a foundational component for motor starters and automated control systems, offering robust electrical performance and long operational life. Its compact design and standardized mounting make it suitable for seamless integration into industrial control panels where space and efficiency are critical.

Features

• Range: TeSys D
• Type: Contactor (Relay/Control Module)
• Proven reliability in industrial switching operations
• Optimized for seamless integration with automation systems
• Manufactured to high-quality standards for consistent performance

Applications

• Motor control and starting
• Industrial automation and process control
• Power distribution and switching circuits
• HVAC and lighting control systems

Technical Specifications

Installation Guidelines

• Mounting: Designed for standard DIN rail or panel mounting. Ensure the installation surface is level and clean.
• Wiring: Connect power and control leads according to the terminal markings. Ensure wires are stripped to the correct length and tightened to the manufacturer's recommended torque to prevent loose connections.
• Environment: Install within a protected enclosure to prevent exposure to dust, moisture, or extreme temperature variations.
• Maintenance: Periodically inspect terminal connections for tightness and check for any signs of electrical arcing or debris build-up during routine maintenance cycles.
