Schneider Electric LRD332 TeSys D Thermal Overload Relay

SKU LRD332

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: LRD332
Origin France
Product Type: Overload relays
Payment: T/T, Western Union
Weight: 0.39 kg
Dimensions: 13,6cm x 10,4cm x 6,2cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The LRD332 is a professional-grade thermal overload relay from the TeSys D range, engineered by Schneider Electric to provide reliable motor protection against overloads and phase failures. Designed with a current adjustment range of 23–32 A and a Class 10A trip class, this relay is built for efficiency and safety in industrial motor control circuits. The inclusion of EverLink BTR terminal technology ensures long-term connection reliability, effectively reducing the need for periodic retightening and maintenance.

Features

Protection Range: Adjustable setting range from 23 A to 32 A
Trip Class: Class 10A for standard motor starting applications
Connection Technology: EverLink BTR screw connectors for superior, vibration-resistant contact quality
Durability: Robust construction designed for continuous industrial operation
Compatibility: Designed for integration with TeSys D contactors

Applications

Industrial motor control centers (MCCs)
Pump and fan control systems
Conveyor belt and material handling motors
Compressors and HVAC motor starters
General industrial machine automation

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Brand	Tesys D
Product Type	Overload relays
Setting Range	23 A – 32 A
Trip Class	10A
Dimensions	13.60 cm x 10.40 cm x 6.20 cm
Weight	0.39 kg
Commodity Code	85364190
ECCN	N
Product Phase	Active

Installation Guidelines

Integration: Mount the LRD332 directly onto a compatible TeSys D contactor for a compact, integrated starter solution, or use an independent mounting kit if required.
Setup: Use the adjustment dial on the front of the unit to set the trip current according to the motor's full-load amperage (FLA) rating.
Wiring: Utilize the EverLink BTR terminals to secure conductors. Ensure cables are stripped to the correct length to achieve the full benefit of the EverLink connection technology.
Testing: Use the manual test function to simulate a trip and verify the functionality of the auxiliary contact monitoring circuit before full system startup.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the current adjustment range for the LRD332?

The LRD332 has an adjustable current range of 23 A to 32 A.

What does the EverLink BTR technology provide?

EverLink BTR connectors ensure high-quality, long-lasting electrical connections and significantly reduce the need for maintenance or retightening.

What is the trip class of this relay?

The relay is rated as Class 10A.

Is this product suitable for use with TeSys D contactors?

Yes, the LRD332 is designed specifically for seamless integration with the TeSys D contactor range.
