Description

The 140EHC10500 is a Modicon Quantum high-speed counter module engineered by Schneider Electric for rigorous industrial automation applications. This advanced counting and positioning module features 8 inputs and is capable of processing high-frequency signals up to 100,000 Hz, making it ideal for rapid event counting, pulse measurement, and precise encoder interfacing. Built for heavy-duty process control and discrete manufacturing environments, it integrates smoothly into standard Modicon Quantum PLC racks. Typical industrial applications include high-speed packaging lines, rotary cutting machines, flow measurement systems, and automated conveyor sorting stations. It is fully compatible with Schneider Electric Modicon Quantum backplane architectures and Unity Pro programming environments.

Features

• Modicon Quantum high-speed counter module designed for precision industrial counting
• 8 high-speed inputs supporting pulse frequencies up to 100,000 Hz
• Robust industrial hardware architecture for continuous heavy-duty operation
• Seamless integration into standard Quantum PLC racks and backplanes

Applications

• High-speed packaging and bottling production lines
• Rotary knife and cut-to-length machine control systems
• Industrial flow measurement and totalization loops
• Automated conveyor tracking and sorting systems

Technical Specifications

Installation Guidelines

• Insert the counter module carefully into an available slot on the Modicon Quantum backplane rack within the control cabinet.
• Secure the module retaining screws to ensure a solid mechanical connection and proper electrical grounding to the rack chassis.
• Connect high-speed sensor or encoder signal wiring to the 8 input terminals using properly shielded cables to prevent electrical noise interference.
• Configure the counting parameters, operating modes, and scaling factors using the compatible PLC programming software before system startup.
