Schneider Electric TSXCTZ1A Modicon TSX Micro 40 kHz Fast Counter Module

SKU TSXCTZ1A

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: TSXCTZ1A
Origin France
Product Type: Fast Counter Modules
Payment: T/T, Western Union
Weight: 0.2 kg
Dimensions: 7.60 cm x 5.10 cm x 12.70 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Industrial automation architectures utilizing the Modicon TSX Micro platform can implement high-speed pulse processing with the TSXCTZ1A counter module. This hardware component provides dedicated counting channels designed to interface directly with incremental encoders, proximity sensors, and pulse generators, offloading high-frequency calculation tasks from the main central processing unit. By handling rapid input transitions independently, the module ensures precise positioning, velocity monitoring, and event triggering without degrading PLC scan times.

Engineered for seamless backplane integration, the TSXCTZ1A occupies a single slot within the TSX Micro rack. Its compact physical profile allows system designers to maximize cabinet space while maintaining robust signal processing capabilities. The module is widely utilized in legacy system maintenance, machine retrofits, and specialized manufacturing processes requiring reliable high-frequency pulse acquisition.

Features

Dedicated high-speed counting channels designed for real-time pulse processing.
Maximum input frequency capability of 40 kHz for high-resolution encoder feedback.
Direct backplane communication with Modicon TSX Micro controllers.
Compact form factor optimized for high-density control cabinet layouts.
Reliable hardware-based counting independent of the PLC CPU scan cycle.

Applications

Packaging and material handling systems requiring precise cut-to-length control.
Positioning and speed measurement of conveyor belts and rotary tables.
Flow measurement and batch control in industrial liquid processing.
Rotary encoder feedback processing in manufacturing machinery and assembly lines.

Technical Specifications

Parameter	Specification
Manufacturer	Schneider Electric
Part Number/Model	TSXCTZ1A
Series	Modicon TSX Micro
Module Type	Fast Counter Module
Maximum Counting Frequency	40 kHz
Dimensions	7.60 cm x 5.10 cm x 12.70 cm
Weight	0.20 kg
Commodity Code	85371099

Installation Guidelines

Ensure the PLC rack is completely powered down before inserting or removing the TSXCTZ1A module to prevent electrical damage to the backplane.
Use shielded twisted-pair (STP) cabling for all high-speed counter inputs to minimize electromagnetic interference (EMI) from adjacent power lines.
Route sensor and encoder signal lines through dedicated low-voltage wire ducts, maintaining physical separation from high-voltage AC power cables.
Verify correct grounding of the cable shields at the designated chassis ground point on the PLC rack.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the maximum counting frequency of the TSXCTZ1A?

The TSXCTZ1A supports a maximum counting frequency of 40 kHz.

Which PLC series is compatible with the TSXCTZ1A module?

This counter module is designed specifically for integration with the Schneider Electric Modicon TSX Micro PLC range.

What type of cabling is recommended for the high-speed inputs?

Shielded twisted-pair (STP) cabling is highly recommended to protect the high-frequency signals from electromagnetic interference.
