Schneider Electric Magelis XBTGT4340 Advanced Touchscreen Panel

SKU XBTGT4340

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: XBTGT4340
Origin France
Product Type: Touch panels
Payment: T/T, Western Union
Weight: 1.8 kg
Dimensions: 21,50cm x 17,00cm x 6,00cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The XBTGT4340 is a high-performance Magelis XBT GT advanced touchscreen panel, designed to provide a sophisticated human-machine interface (HMI) for industrial automation. Featuring a 7.5-inch display with a 320 x 240 pixel QVGA resolution, this terminal offers clear visualization of process data, machine states, and diagnostic information. Powered by a 24 V DC supply, the panel is built to withstand demanding operating conditions while providing a responsive and intuitive touch interface for operators. It serves as a vital visualization node in automated systems, allowing for efficient control, monitoring, and interaction with PLC architectures.

Features

Advanced Interface: Responsive touchscreen technology for streamlined operator interaction.
Display Quality: 7.5-inch QVGA (320 x 240) resolution for clear graphical visualization.
Compact Design: Optimized dimensions for seamless integration into control cabinet doors or operator panels.
Industrial Robustness: Engineered for reliable performance in harsh industrial environments.
Magelis Ecosystem: Full integration capabilities within the Schneider Electric Magelis visualization software environment.

Applications

Operator control stations for industrial machinery and assembly lines.
Process visualization and data logging in manufacturing environments.
Industrial building automation and control interfaces.
Replacement and maintenance for existing Magelis XBT GT HMI installations.

Technical Specifications

Category	Specification
Manufacturer	Schneider Electric
Range	Magelis XBT GT
Product Type	Touch panels
Display Size	7.5 inch
Resolution	320 x 240 (QVGA)
Supply Voltage	24 V DC
Product Phase	Phase-Out
Weight	1.80 kg
Dimensions	21.50 x 17.00 x 6.00 cm
Commodity Code	85371099

Installation Guidelines

Cutout Dimensions: Ensure the cabinet panel cutout matches the manufacturer’s specified mounting dimensions to guarantee a secure, gasket-sealed fit.
Gasket Sealing: Periodically inspect the rear mounting gasket to ensure the HMI maintains its ingress protection rating (IP) against moisture and dust.
Power Supply: Connect to a stable 24 V DC power source; ensure polarity is correct and the supply is filtered to avoid signal noise on the touch interface.
Cable Routing: Keep communication cables away from high-voltage wiring and motors to prevent electromagnetic interference (EMI) that could affect display stability or touch sensitivity.
Grounding: Always connect the panel's frame ground terminal to the main cabinet ground to ensure personal safety and reduce potential noise issues.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the screen size and resolution of the XBTGT4340?

The panel features a 7.5-inch display with a resolution of 320 x 240 pixels (QVGA).

What power supply does this HMI panel require?

It is designed to operate on a 24 V DC power supply.

What should I check when installing this panel in a control cabinet?

You should ensure the mounting cutout is accurate for the unit dimensions and that the protective gasket is properly seated to maintain the panel's IP rating.
