Schneider Electric TSXMRP232P Modicon Quantum Memory Module

SKU TSXMRP232P

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: TSXMRP232P
  • Origin France
  • Product Type: MeMory Modules
  • Payment: T/T, Western Union
  • Weight: 0.1 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

MeMory Modules Modicon Quantums
Quantità
Call sales Contact

Product Description

Description

The TSXMRP232P is a 32K x 16-bit RAM memory module designed for the Modicon Quantum automation platform. This memory component provides reliable volatile data storage, serving as a critical resource for controller program execution, data logging, and configuration management within the Quantum architecture. Engineered for high operational stability, this module ensures fast read/write access speeds required for maintaining the real-time performance of industrial control systems. Its compact and lightweight design allows for straightforward integration into existing Quantum racks, facilitating efficient system upgrades or maintenance in legacy installations.

Features

  • 32K x 16-bit capacity for data and program storage.
  • Optimized for high-speed data access within the Modicon Quantum system.
  • Compact form factor for efficient rack space utilization.
  • Robust design tailored for demanding industrial environments.

Applications

  • Industrial automation and process control memory expansion.
  • Legacy system maintenance and hardware lifecycle management.
  • Data buffering for complex logic and HMI interface synchronization.
  • Secure storage for controller configuration parameters.

Technical Specifications

Parameter Specification
Manufacturer Schneider Electric
Range Modicon Quantum
Model TSXMRP232P
Product Type RAM Memory Module
Capacity 32K x 16-bit
Weight 0.10 kg
Product Phase Phase-Out
Commodity Code 85371099

Installation Guidelines

  • Ensure the controller is powered down and the backplane is de-energized before inserting or removing the memory module to prevent data corruption or hardware damage.
  • Handle the module by its edges and use an anti-static wrist strap to avoid electrostatic discharge (ESD) damage to sensitive components.
  • Align the module correctly with the corresponding slot on the Quantum backplane or processor housing, ensuring the keying mechanism is properly seated before applying pressure.
  • Once installed, verify that the module is recognized by the CPU via the system diagnostic software.
  • Keep the module in a cool, dry environment and away from high-temperature sources to preserve the integrity of the memory chips.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the memory capacity of the TSXMRP232P?
The module provides 32K x 16-bit of RAM storage capacity.
What is the primary function of this module?
It serves as a volatile memory storage unit for program execution and data management in Modicon Quantum controllers.
Are there special handling requirements for this module?
Yes, it is sensitive to electrostatic discharge (ESD) and should be handled with anti-static precautions.
