Memory capacity expansion for Modicon Quantum controllers is achieved using the TSXMRPC003MC PCMCIA SRAM memory card. This configurable memory extension module provides reliable volatile storage for application programs, register data, and system configuration files within the host processor. By expanding the available memory footprint, it allows industrial automation systems to execute larger, more complex control logic programs and manage extensive data logging requirements directly at the controller level.
The card utilizes high-speed Static RAM (SRAM) technology, ensuring rapid read and write access times compatible with the demanding execution cycles of Modicon Quantum CPUs. It features a configurable architecture, allowing system engineers to partition the memory space between application code and data storage to optimize processor performance. An integrated backup battery safeguards stored data against power interruptions, maintaining memory integrity even when the card is removed from the processor slot.
| Manufacturer | Schneider Electric |
| Part Number/Model | TSXMRPC003MC |
| Product Range | Modicon Quantum |
| Product Type | Configurable SRAM Memory Card |
| Memory Capacity (Application) | 192 KB to 3072 KB |
| Memory Capacity (Data) | 2880 KB to 0 KB |
| Memory Type | SRAM (Static RAM) |
| Physical Interface | PCMCIA Type I |
| Data Retention | Battery-backed SRAM |
Before installing or removing the memory card, ensure that the Modicon Quantum processor is powered down or follow the specific hot-swap procedures outlined in the CPU hardware manual. Align the TSXMRPC003MC card with the PCMCIA slot guide rails on the processor module and slide it firmly into place until the eject button engages. Avoid touching the connector pins to prevent electrostatic discharge (ESD) damage. Regularly inspect and replace the auxiliary backup battery according to the manufacturer's maintenance schedule to guarantee continuous data retention during power outages.
Global Express Shipping
Returns & Warranty
Manufacturer: Schneider Electric
Product No.: TSXMRPC003MC
Country of origin:France
Product Type: Memory Cards
Payment: T/T, Western Union
Weight: 4530g
Shipping port: Xiamen
Warranty: 12 months
Memory capacity expansion for Modicon Quantum controllers is achieved using the TSXMRPC003MC PCMCIA SRAM memory card. This configurable memory extension module provides reliable volatile storage for application programs, register data, and system configuration files within the host processor. By expanding the available memory footprint, it allows industrial automation systems to execute larger, more complex control logic programs and manage extensive data logging requirements directly at the controller level.
The card utilizes high-speed Static RAM (SRAM) technology, ensuring rapid read and write access times compatible with the demanding execution cycles of Modicon Quantum CPUs. It features a configurable architecture, allowing system engineers to partition the memory space between application code and data storage to optimize processor performance. An integrated backup battery safeguards stored data against power interruptions, maintaining memory integrity even when the card is removed from the processor slot.
| Manufacturer | Schneider Electric |
| Part Number/Model | TSXMRPC003MC |
| Product Range | Modicon Quantum |
| Product Type | Configurable SRAM Memory Card |
| Memory Capacity (Application) | 192 KB to 3072 KB |
| Memory Capacity (Data) | 2880 KB to 0 KB |
| Memory Type | SRAM (Static RAM) |
| Physical Interface | PCMCIA Type I |
| Data Retention | Battery-backed SRAM |
Before installing or removing the memory card, ensure that the Modicon Quantum processor is powered down or follow the specific hot-swap procedures outlined in the CPU hardware manual. Align the TSXMRPC003MC card with the PCMCIA slot guide rails on the processor module and slide it firmly into place until the eject button engages. Avoid touching the connector pins to prevent electrostatic discharge (ESD) damage. Regularly inspect and replace the auxiliary backup battery according to the manufacturer's maintenance schedule to guarantee continuous data retention during power outages.
Global Express Shipping
Returns & Warranty
Orders are processed and delivered Monday-Friday (excluding public holidays).
For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
