XBTGK2330

Schneider Electric

Schneider Electric XBTGK2330 Magelis XBT GT Touch Panels

SKU XBTGK2330

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: XBTGK2330
  • Origin France
  • Product Type: Touch panels
  • Payment: T/T, Western Union
  • Weight: 3.4 kg
  • Dimensions: 22,00cm x 26,50cm x 6,00cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Touch Panels
Quantità
Call sales Contact

Product Description

Description

The XBTGK2330 is an advanced touchscreen operator panel with an integrated keyboard manufactured by Schneider Electric within the Magelis XBT GT range. Featuring a 5.7-inch TFT LCD screen with a QVGA resolution of 320 x 240 pixels, this interface device provides clear visual feedback and operator control for industrial automation processes. The XBTGK2330 combines an intuitive touch interface with physical keys to facilitate efficient data entry and machine monitoring in demanding industrial environments.

Features

  • 5.7-inch TFT LCD touchscreen with 320 x 240 pixels QVGA resolution
  • Integrated physical keyboard for rapid and reliable data entry
  • Designed specifically for industrial automation and process control
  • Built by Schneider Electric for robust long-term operational performance

Applications

  • Industrial machine control panels
  • Automated production and assembly lines
  • Process monitoring and visualization systems
  • Operator interface stations in manufacturing plants

Technical Specifications

Parameter Specification
Brand Schneider Electric
Manufacturer Schneider Electric
Range Magelis XBT GT
Type of product Touch panels
Product phase Phase-Out
Dimensions 22,00 x 26,50 x 6,00 cm
Weight 3.40 kg
Commodity Code 85371099
Export Control Regulations (ECCN) N

Installation Guidelines

  • Mount the touch panel securely into an appropriate cutout on a control cabinet or console door.
  • Ensure proper gasket sealing between the panel bezel and the enclosure to maintain environmental protection.
  • Route communication cables away from high-voltage power lines to prevent signal interference.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What are the screen size and resolution of the XBTGK2330 panel?
It features a 5.7-inch TFT LCD screen with a QVGA resolution of 320 x 240 pixels.
What input methods are available on this operator panel?
It includes both a touchscreen interface and an integrated physical keyboard.
What are the physical dimensions and weight of the unit?
The dimensions are 22,00 x 26,50 x 6,00 cm, and it weighs 3.40 kg.
