Description

The LXM28AU15M3X is a high-performance Servo Drive from the Lexium 28 series, specifically engineered for precision motion control applications. This drive supports both single-phase and three-phase power supplies with an operating voltage range of 200/230V. With a power rating of 1.5 kW, it is designed to provide smooth, efficient, and accurate control for servo motors in diverse automated machinery. The LXM28AU15M3X is a versatile solution for industrial environments requiring dynamic speed and torque management, maintaining active status for current and future automation projects.

Features

• Compatible with the Lexium 28 servo drive ecosystem
• Flexible power input: Supports both single-phase and three-phase supplies
• Rated power output of 1.5 kW for demanding motion tasks
• Optimized for high-precision motor control and synchronization
• Compact physical design suitable for integrated control cabinet mounting

Applications

• Material handling and conveyor systems
• Packaging and bottling machinery
• Labeling and printing equipment
• Electronic component assembly
• Robotic arms and positioning systems

Technical Specifications

Installation Guidelines

• Mounting: Mount the drive vertically in a clean, ventilated control cabinet to ensure optimal heat dissipation. Maintain recommended clearances around the unit.
• Wiring: Use appropriately rated shielded cables for motor and encoder connections to minimize electrical noise. Ensure proper phase connection for three-phase supply configurations.
• Grounding: Secure a robust chassis ground to the cabinet's grounding busbar to meet EMC compliance and ensure operator safety.
• Environment: Protect the unit from extreme temperatures, moisture, and conductive contaminants. Observe the specified ambient operating temperature limits.
• Commissioning: Ensure all safety circuits are wired correctly before applying power. Use compatible Schneider Electric software to configure the drive parameters for the specific motor model.
