Schneider Magelis XBTGC2230U Controller Panel

SKU XBTGC2230U

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: XBTGC2230U
Origin France
Product Type: Controllers
Payment: T/T, Western Union
Weight: 5.0 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The XBTGC2230U is a Magelis XBT GC series 5.7-inch color controller panel engineered for integrated control and visualization in industrial environments. This device combines HMI functionality with integrated I/O, featuring 16 digital inputs and 16 digital outputs (sink configuration) to facilitate direct management of automation tasks. The XBTGC2230U is designed to provide reliable operation and system monitoring, serving as an effective solution for maintaining or extending the service life of existing industrial automation architectures.

Features

5.7-inch color display for clear process visualization
Integrated controller functionality
16 digital inputs
16 digital outputs (sink type)
Compact design suitable for panel mounting
Proven technology for legacy system support

Applications

Industrial machinery control
Process automation monitoring
Automated production lines
Legacy system maintenance and upgrades
Human-Machine Interface (HMI) integration

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Range	Magelis XBT GC
Product Type	Controller
Display Size	5.7 inch
Digital Inputs	16
Digital Outputs	16 (Sink)
Product Phase	Obsolete
Weight	5.00 kg
Commodity Code	85371091
Export Control Regulations	N

Installation Guidelines

Panel Mounting: Ensure the control panel cutout dimensions conform to manufacturer specifications to maintain the integrity of the enclosure seal.
Wiring: Utilize appropriate wire gauges for the 16 input and 16 output terminals. Ensure sink-type configurations are correctly wired to match the connected field devices.
Grounding: Connect the chassis ground terminal to a clean earth point to minimize electrical noise and protect the internal circuitry.
Environmental Considerations: Although the unit is designed for industrial use, ensure it is installed in an environment within the specified temperature and humidity range to prevent component degradation.
Power Supply: Verify that the supply voltage matches the requirements of the controller to prevent operational failure or damage.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the I/O configuration of the XBTGC2230U?

This controller panel is equipped with 16 digital inputs and 16 digital outputs, both utilizing a sink configuration.

What is the screen size of this controller panel?

The XBTGC2230U features a 5.7-inch color display.

What is the current lifecycle status of this product?

The XBTGC2230U is classified as obsolete, though it remains a viable option for maintaining existing installations.
