Schneider Modicon Premium TSXAEY1614C Analog Module

SKU TSXAEY1614C

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: TSXAEY1614C
Origin France
Product Type: Analog Modules
Payment: T/T, Western Union
Weight: 0.45 kg
Dimensions: 18,00cm x 26,00cm x 5,50cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The TSXAEY1614C is a high-precision analog input module for the Modicon Premium automation platform, specifically configured for thermocouple signal acquisition. This module provides 16 input channels with 16-bit resolution, enabling high-accuracy temperature monitoring required for critical industrial process control. Designed to interface directly with various thermocouple types, the TSXAEY1614C converts raw thermal data into digital values that can be utilized by the PLC for precise regulation and monitoring. Its design ensures robust noise immunity and reliable data acquisition in demanding automation environments.

Features

16 analog input channels dedicated to thermocouple signals.
High 16-bit resolution for precise thermal data processing.
Integrated into the Modicon Premium range for seamless PLC integration.
Robust design tailored for industrial process control stability.
Facilitates accurate temperature measurement across diverse industrial applications.

Applications

Industrial oven and furnace temperature control.
Heat treatment process monitoring.
HVAC and environmental thermal management.
Critical process control loops requiring high-accuracy thermocouple input.

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Range	Modicon Premium
Product Type	Analog modules
Input Capacity	16 Inputs
Signal Type	Thermocouple
Resolution	16 bits
Dimensions	18.00 x 26.00 x 5.50 cm
Weight	0.45 kg
Product Phase	Phase-Out
Commodity Code	85371099

Installation Guidelines

Mounting: Insert the module into a compatible slot on the Modicon Premium rack, ensuring the rear connector is properly locked into the backplane.
Wiring: Use thermocouple-grade extension wire that matches the specific thermocouple type used to prevent cold junction errors.
Shielding: Employ shielded instrumentation cable for all thermocouple runs to minimize electromagnetic interference (EMI) and maintain signal integrity.
Grounding: Connect the cable shields to a single-point earth ground to avoid ground loops, which can cause significant measurement inaccuracies.
Configuration: Configure the input channel types (e.g., J, K, T type) within the PLC programming software to match the physical sensors connected to the module.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the TSXAEY1614C?

The TSXAEY1614C is an analog input module designed for high-resolution thermocouple temperature monitoring in Modicon Premium PLC systems.

How many inputs does this module provide?

This module features 16 analog input channels.

What is the resolution of this analog module?

The module provides 16-bit resolution for precise signal processing.

Why is shielding important for this module?

Shielding is critical for thermocouple inputs to reduce electromagnetic interference and prevent ground loops that could lead to measurement inaccuracies.
