Description

The ATV16U54N4 is a variable frequency drive from the Altivar 16 series, designed to provide efficient speed and torque control for three-phase industrial motors. With an apparent power rating of 5.4 kVA and designed for operation on 400/460 V three-phase power supplies, this drive is a reliable solution for various motor-driven applications. The unit is housed in an IP31-rated enclosure, providing a degree of protection against falling objects and dripping water, making it suitable for installation in basic industrial control environments.

Features

• Rated for 5.4 kVA power capacity.
• Compatible with 400/460 V three-phase power inputs.
• IP31 enclosure rating for protected installation environments.
• Altivar 16 architecture for standardized motor speed control.
• Compact and robust design for integration into motor control centers.

Applications

• Industrial fan and pump control systems.
• General machinery and conveyor belt speed regulation.
• HVAC system components.
• Optimized speed control for 3-phase asynchronous motors.

Technical Specifications

Installation Guidelines

• Mounting: Install the drive in a vertical orientation within a clean, ventilated enclosure to ensure optimal heat dissipation and prevent component overheating.
• Clearance: Maintain adequate free space above and below the drive to facilitate airflow through the cooling vents.
• Wiring: Connect the 3-phase power supply to the input terminals and the motor leads to the output terminals, following proper torque settings for secure connections.
• Grounding: Establish a high-integrity connection to the system earth ground to ensure safe operation and reduce electromagnetic interference.
• Safety: Ensure all input power is completely isolated and verified before performing any installation or maintenance tasks.
