Schneider Modicon Premium TSXDSY08R4D Digital Output Module

SKU TSXDSY08R4D

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: TSXDSY08R4D
Origin France
Product Type: Digital Modules
Payment: T/T, Western Union
Weight: 0.53 kg
Dimensions: 18cm x 26cm x 5,5cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The TSXDSY08R4D is a discrete relay output module engineered for the Modicon Premium automation platform. This module features 8 independent relay outputs, providing electrical isolation between the control system and high-power field devices. It is designed to handle discrete switching tasks with high reliability, making it an effective choice for interface applications where potential-free contacts are required to manage industrial actuators, contactors, or signal indicators.

Features

8 discrete relay output channels
Potential-free relay contact switching
Designed for Modicon Premium rack architecture
Robust design for industrial control environments
Ideal for interface between PLC and high-voltage or isolated circuits

Applications

Industrial actuator and solenoid control
Interfacing PLC outputs to high-voltage circuits
Automated relay and contactor switching
Signal isolation in control systems

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Range	Modicon Premium
Product Type	Discrete Output Module
Channels	8
Output Type	Relay
Dimensions (cm)	18.00 x 26.00 x 5.50
Weight	0.53 kg
Commodity Code	85389091

Installation Guidelines

Mounting: Seat the module securely into the Modicon Premium rack slot to ensure proper backplane power and communication connectivity.
Wiring: Connect field loads to the relay contacts. Ensure that the switching current and voltage do not exceed the maximum ratings specified in the module's technical documentation to prevent relay contact welding.
Inductive Loads: When switching inductive loads (such as coils or solenoids), install appropriate surge suppression (e.g., flyback diodes or RC snubbers) across the load to protect the relay contacts from arcing.
Environment: Install in a clean, dry control enclosure protected from excessive dust and corrosive atmospheres.
Maintenance: Periodically verify the integrity of the relay contacts by monitoring output cycle performance and listening for successful contact actuation.
