Schneider Modicon Premium TSXDSY16R5C Digital Output Module

SKU TSXDSY16R5C

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: TSXDSY16R5C
Origin France
Product Type: Digital Modules
Payment: T/T, Western Union
Weight: 0.19 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The TSXDSY16R5C is a Modicon Premium discrete output module featuring 16 relay outputs designed for robust signal switching in industrial control applications. This module operates within a voltage range of 12 V DC to 24 V DC and supports switching loads up to 3 A per channel. The relay-based architecture provides galvanic isolation between the controller and the field devices, making it highly effective for driving various actuators, contactors, and solenoids in legacy Modicon Premium automation systems.

Features

16 relay-based digital outputs
Rated operational voltage: 12-24 V DC
Switching capacity: 3 A per channel
Galvanic isolation for enhanced signal integrity
Designed for the Modicon Premium automation platform
Reliable switching for diverse industrial loads

Applications

Industrial automation process control
Actuator and solenoid valve management
Contactor control in automation panels
Signal interfacing for field instrumentation
Logic control implementation in complex systems

Technical Specifications

Specification	Details
Manufacturer	Schneider Electric
Range	Modicon Premium
Product Type	Digital modules
Number of Outputs	16
Output Type	Relay (not protected)
Voltage Rating	12 - 24 V DC
Current Rating	3 A (per channel)
Weight	0.19 kg
Commodity Code	85371099
Product Status	Phase-Out

Installation Guidelines

Mounting: Securely insert the module into the designated slot on the Modicon Premium rack. Ensure the backplane interface is correctly aligned and locked.
Wiring: Connect field devices to the relay output terminals. Due to the relay nature of the outputs, ensure current limits are respected to prevent contact welding or degradation.
Protection: Because these outputs are not internally protected, it is highly recommended to install external fusing or surge suppression devices (such as RC networks or flyback diodes) to protect the relay contacts from inductive load transients.
Safety: Verify that the system power is disconnected before performing any maintenance or wiring modifications to the module terminals.
Environment: Maintain the rack in an environment free from excessive vibration, heat, and conductive particulates to ensure stable relay operation.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the output configuration for the TSXDSY16R5C?

The module features 16 relay outputs.

What are the electrical ratings for each output channel?

Each relay output is rated for 12-24 V DC operation with a maximum current of 3 A.

Does this module include integrated protection for the outputs?

No, the relay outputs on this module are not internally protected.

What is the lifecycle status of this module?

The TSXDSY16R5C is currently classified in the Phase-Out product lifecycle stage.
