Schneider Modicon Quantum 140DDO35301 Digital Output Module

SKU 140DDO35301

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: 140DDO35301
  • Origin France
  • Product Type: Digital Modules
  • Payment: T/T, Western Union
  • Weight: 0.42 kg
  • Dimensions: 16,50cm x 31,00cm x 5,00cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Digital Output Modules
Quantità
Call sales Contact

Product Description

Description

The 140DDO35301 is a 32-channel digital output module designed for the Modicon Quantum automation range. It provides high-density signal control, operating at 24 V DC with a source output configuration. The module is engineered with four isolated output groups (8 outputs per group), allowing for segmented control of field devices and enhanced protection against electrical interference between different segments of the control architecture.

Features

  • 32 digital output channels
  • 24 V DC operating voltage
  • Source output configuration
  • 4 individually isolated output groups
  • Optimized for Modicon Quantum high-density I/O racks

Applications

  • High-density industrial machine control
  • Segmented actuator and solenoid valve management
  • Automated relay and contactor switching
  • Large-scale distributed I/O control systems

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Range Modicon Quantum
Product Type Digital Output Module
Channels 32
Output Type Source
Operating Voltage 24 V DC
Isolation 4 Groups
Dimensions (cm) 16.50 x 31.00 x 5.00
Weight 0.42 kg
Commodity Code 85389091

Installation Guidelines

  • Mounting: Secure the module into a dedicated slot on the Modicon Quantum backplane. Ensure the locking tabs are firmly engaged for proper electrical contact.
  • Wiring: Connect field devices to the corresponding terminals. Because this is a source module, ensure the load is connected between the output terminal and the common ground.
  • Grouping: Respect the grouping configuration; ensure that devices requiring different supply rails or segments are mapped to the correct isolated group.
  • Safety: Always verify that the external power supply for the output loads is within the 24 V DC tolerance before enabling the outputs.
  • Maintenance: Periodically inspect terminal blocks for tightness and check that the module's diagnostic LEDs indicate proper operation.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
How are the outputs organized in the 140DDO35301?
The module features 32 digital outputs organized into four isolated groups of eight.
Is this a sink or source output module?
The 140DDO35301 is configured as a source output module.
What is the primary operating voltage?
The module operates at a nominal voltage of 24 V DC.
Which system series is this module designed for?
It is designed for the Modicon Quantum automation range.
Reviews

More from this brand

Schneider 170XTS00200 Modicon Momentum/Quantum Spring Terminal Block
170XTS00200Schneider 170XTS00200 Modicon Momentum/Quantum Spring Terminal Block
Schneider TSXP57303AMC Modicon Premium Double-Format PL7 Processor
TSXP57303AMCSchneider TSXP57303AMC Modicon Premium Double-Format PL7 Processor
Schneider 170ADM69051 Modicon Momentum Discrete I/O Base (10I/8O)
170ADM69051Schneider 170ADM69051 Modicon Momentum Discrete I/O Base (10I/8O)
Schneider Electric ATV212WU22N4C Altivar 212 Variable Frequency Drive
ATV212WU22N4CSchneider Electric ATV212WU22N4C Altivar 212 Variable Frequency Drive

140DDO35301

Stock & lead time on request

Call
  • 140DDO35301
1 1

Schneider Modicon Quantum 140DDO35301 Digital Output Module

Only 5 item(s) left in stock

  • Manufacturer: Schneider Electric

  • Product No.: 140DDO35301

  • Country of origin:France

  • Product Type: Digital Modules

  • Payment: T/T, Western Union

  • Weight: 420g

  • Dimensions: 16,50cm x 31,00cm x 5,00cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

The 140DDO35301 is a 32-channel digital output module designed for the Modicon Quantum automation range. It provides high-density signal control, operating at 24 V DC with a source output configuration. The module is engineered with four isolated output groups (8 outputs per group), allowing for segmented control of field devices and enhanced protection against electrical interference between different segments of the control architecture.

Features

  • 32 digital output channels
  • 24 V DC operating voltage
  • Source output configuration
  • 4 individually isolated output groups
  • Optimized for Modicon Quantum high-density I/O racks

Applications

  • High-density industrial machine control
  • Segmented actuator and solenoid valve management
  • Automated relay and contactor switching
  • Large-scale distributed I/O control systems

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Range Modicon Quantum
Product Type Digital Output Module
Channels 32
Output Type Source
Operating Voltage 24 V DC
Isolation 4 Groups
Dimensions (cm) 16.50 x 31.00 x 5.00
Weight 0.42 kg
Commodity Code 85389091

Installation Guidelines

  • Mounting: Secure the module into a dedicated slot on the Modicon Quantum backplane. Ensure the locking tabs are firmly engaged for proper electrical contact.
  • Wiring: Connect field devices to the corresponding terminals. Because this is a source module, ensure the load is connected between the output terminal and the common ground.
  • Grouping: Respect the grouping configuration; ensure that devices requiring different supply rails or segments are mapped to the correct isolated group.
  • Safety: Always verify that the external power supply for the output loads is within the 24 V DC tolerance before enabling the outputs.
  • Maintenance: Periodically inspect terminal blocks for tightness and check that the module's diagnostic LEDs indicate proper operation.
