The Schneider Modicon TSX Micro TSXDSZ08T2 is a protected transistor discrete output module designed for industrial automation control systems. Engineered for high-density switching applications within the Modicon TSX Micro architecture, this unit features 8 protected transistor outputs rated at 0.5 A each. Supplied complete with an integrated terminal block for direct wiring connections, the TSXDSZ08T2 ensures reliable signal distribution and control execution for automated machinery and industrial processes.
8 protected transistor outputs rated at 0.5 A
Integrated terminal block for direct and secure field wiring
Designed specifically for Modicon TSX Micro automation racks
Phase-out lifecycle status supporting legacy system maintenance and retrofits
Industrial machinery and discrete manufacturing control
Actuator and solenoid valve interfacing
Conveyor routing and material handling systems
Legacy Modicon automation architecture maintenance
| Specification | Value |
| Manufacturer | Schneider Electric |
| Brands | Schneider Electric |
| Range | Modicon TSX Micro PLM |
| Model / Part Number | TSXDSZ08T2 |
| Product Phase | Phase-Out |
| Output Type | Protected Transistor Output (0.5 A) |
| Dimensions | 5,5 x 26 x 5,5 cm |
| Weight | 0.33 kg |
| Commodity Code | 85389091 |
| Export Control Regulations (ECCN) | N |
Ensure control power is completely disconnected before installing or removing the module from the rack.
Securely terminate field wiring to the integrated terminal block following standard torque specifications.
Route low-level I/O signal wiring away from high-voltage power lines to mitigate electromagnetic interference.
Verify proper module seating and backplane connection prior to system startup.
Global Express Shipping
Returns & Warranty
Manufacturer: Schneider Electric
Product No.: TSXDSZ08T2
Country of origin:France
Product Type: Discrete Output Modules
Payment: T/T, Western Union
Weight: 330g
Dimensions: 5,5cm x 26cm x 5,5cm
Shipping port: Xiamen
Warranty: 12 months
