Schneider TSXCAY42C Modicon Premium Motion Control Module

SKU TSXCAY42C

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: TSXCAY42C
  • Origin France
  • Product Type: Control Modules
  • Payment: T/T, Western Union
  • Weight: 0.2 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Modicon Premiums Motion Control Modules
Quantità
Call sales Contact

Product Description

Description

The TSXCAY42C is a 4-axis motion control module developed for the Modicon Premium automation platform. This control module is optimized for high-precision servomotor applications, providing complex motion profile management with cycle times ranging from 8 ms to 10 s. It functions as a key interface between the controller and servodrives, enabling synchronized, multi-axis positioning and velocity regulation in demanding industrial environments.

Features

  • 4-axis independent or synchronized motion control.
  • Configurable cycle timing range from 8 ms to 10 s.
  • Seamless backplane integration with the Modicon Premium range.
  • Robust design suitable for high-precision industrial motion tasks.
  • Compact, rack-mounted modular form factor.

Applications

  • Multi-axis synchronization for robotic arms.
  • Precision positioning in packaging and labeling machinery.
  • Speed control and trajectory management for conveyor systems.
  • Automated assembly line motion orchestration.
  • Machine tool axis control and integration.

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Range Modicon Premium
Product Type Motion Control Module
Number of Axes 4
Cycle Timing 8 ms to 10 s
Weight 0.20 kg
Commodity Code 85371099
Lifecycle Status Phase-Out

Installation Guidelines

  • Backplane Integration: Ensure the TSXCAY42C is securely engaged in the appropriate rack slot to maintain stable communication with the processor.
  • Signal Protection: Employ shielded cables for servomotor feedback loops to prevent electromagnetic interference (EMI) from affecting motion accuracy.
  • Cable Separation: Keep motion control signal cables physically separate from high-power AC/DC lines to ensure signal integrity.
  • Grounding: Establish a solid common ground connection for the control rack to protect the module from static discharge and noise.
  • Thermal Management: Ensure sufficient airflow around the rack assembly to maintain ambient temperature within standard operating limits.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
How many axes of motion can the TSXCAY42C manage?
The module is designed to manage up to 4 axes of motion control.
What is the supported cycle time range for this module?
It supports motion control cycle times between 8 ms and 10 s.
What is the current product lifecycle status of this module?
This module is officially classified as a Phase-Out product by the manufacturer.
Which PLC series is this module compatible with?
The TSXCAY42C is part of the Modicon Premium range and is compatible with its associated backplane architectures.
